BAB2090S
BAB2090S
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
BAB2090S Specifications
View Full SpecificationsView Specifications
BAB2090S, Cutler Hammer, Eaton, Westinghouse, Quicklag, type BAB, P, PH, A, 120/V, , standard interrupting capacity, complete with 120V shunt trip, 40ºC, Bolt-On, trip functions, Thermal Magnetic molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Quicklag | Protection | Thermal Magnetic |
| Connection | Bolt-On | ||
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Quicklag | ||
| Protection | Thermal Magnetic | ||
| Connection | Bolt-On |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
We can test, inspect and repair your BAB2090S. All repairs include a 2-Year Electrical.com Warranty.
The BAB2090S is a miniature circuit breaker from the Eaton BAB series, engineered for reliable branch circuit protection in commercial and industrial electrical distribution systems. This model features a 2-pole configuration, a continuous current rating of A, and is rated for operation up to 120/240V AC. The BAB2090S employs a bolt-on mounting style for secure installation in compatible panelboards and offers a {aic rating} interrupting rating, providing robust short-circuit protection for systems with moderate fault current potential. Notably, the BAB2090S includes a 120V shunt trip feature, enabling remote tripping capability for enhanced safety and control in critical applications.
The BAB series, including the BAB2090S, is recognized for its durable molded case construction, compact footprint, and consistent performance across a range of applications. This breaker is HACR rated, making it suitable for heating, air conditioning, and refrigeration circuits, and is both UL listed and CSA certified for compliance with industry standards. The BAB2090S accommodates both copper and aluminum conductors and is widely used in both new installations and retrofit projects requiring reliable, space-efficient circuit protection.
For projects needing dependable overcurrent protection and remote tripping functionality, the BAB2090S offers a robust solution. Electrical.com provides access to the BAB2090S along with Eaton, Cutler-Hammer and Westinghouse technical documentation, product selection guidance, and expert support to ensure proper specification and reliable performance in your electrical distribution network.
