SEHA36AT0060
SEHA36AT0060
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
SEHA36AT0060 Specifications
View Full SpecificationsView Specifications
SEHA36AT0060, General Electric, ABB, Spectra RMS, type SEHA, P, PH, A, V, , standard interrupting capacity, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable RMS trip unit with trip functions, lugs not included, Solid State Electronic, molded case circuit breakers
| Manufacturer | General Electric | Subcategory | Molded Case |
| Family | Spectra RMS | Protection | Solid State |
| Connection | Bolt-On | ||
| Manufacturer | General Electric | ||
| Subcategory | Molded Case | ||
| Family | Spectra RMS | ||
| Protection | Solid State | ||
| Connection | Bolt-On |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
We can test, inspect and repair your SEHA36AT0060. All repairs include a 2-Year Electrical.com Warranty.
The SEHA36AT0060 is a ‑pole, amp molded‑case circuit breaker from General Electric’s Spectra RMS series, designed for dependable overcurrent protection in industrial and commercial low‑voltage power distribution systems. It is rated for voltages up to 600 VAC and built on the SE150 frame, combining robust mechanical construction with an electronic RMS‑sensing trip system. The bolt‑on style mounting enables secure installation in compatible panelboards and switchgear, making it suitable for feeder and branch circuits that require coordinated protection and high reliability.
Electrically, the SEHA36AT0060 uses a solid‑state, RMS current‑sensing trip unit with adjustable instantaneous and tracking short‑time protection, providing both overload and short‑circuit interruption. The breaker supports field‑installable rating plugs that allow adjustment of the trip current setting without replacing the device, adding flexibility for varying load conditions. At 480 VAC, it commonly carries a 65 kA interrupting rating, with even higher interrupting capacity at lower voltages such as 100 kA at 240 VAC, ensuring effective fault clearing in systems with significant available fault current.
The Spectra RMS family—including this SEHA36AT0060 model—was originally manufactured by General Electric (GE) and remains widely used despite the Spectra line being discontinued following ABB’s acquisition of GE’s electrical distribution business. ABB retains support and retrofit strategies for Spectra breakers in legacy panels, helping ensure continuity for service and replacement needs. As a solid‑state trip MCCB with a high interrupting rating and adjustable trip characteristics, the SEHA36AT0060 is well suited for industrial control panels, distribution boards, and settings where reliable, configurable three‑phase circuit protection is required.
Purchase the SEHA36AT0060 at Electrical.com, your reliable partner for industrial and commercial electrical products including circuit breakers, panel boards, and accessories. Our selection includes manufacturers like General Electric and ABB, backed by a dedicated sales team ready to assist with technical questions, product selection, and support.
