TJD432400WL
TJD432400WL
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
TJD432400WL Specifications
View Full SpecificationsView Specifications
TJD432400WL General Electric Q-Line, Type TJD, 3P, 3PH, 400A, 240V, 22kA@240V, complete with non-interchangeable trip unit and line & load side lug terminals, standard interrupting capacity, 40°C, Feed-Thru, Thermal Magnetic molded case circuit breakers
| Part Number | TJD432400WL | Family | Q-Line |
| Manufacturer | General Electric | Type | TJD |
| Subcategory | Molded Case | Voltage | 240 |
| Part Number | TJD432400WL | ||
| Family | Q-Line | ||
| Manufacturer | General Electric | ||
| Type | TJD | ||
| Subcategory | Molded Case | ||
| Voltage | 240 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
TJD432400WL Specifications:
Part NumberTJD432400WL
Manufacturers
Sub-CategoryMolded Case
FamilyQ-Line
TypeTJD
UPC783164000801
Weight23 lbs
Voltage240
Amperage400
ProtectionThermal Magnetic
Poles3
FunctionsLI - Long-Time and Instantaneous
ConnectionFeed-Thru
Phase3
AIC Rating22kA@240V
Additional Information
Accessories
Similar Products
Need A Repair?
We can test, inspect and repair your TJD432400WL. All repairs include a 2-Year Electrical.com Warranty.
To receive a repair quote, complete the repair form or call our expert sales team for an instant quote.
