LJM36250U31X
LJM36250U31X
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
LJM36250U31X Specifications
View Full SpecificationsView Specifications
LJM36250U31X, Schneider Electric, Square D, PowerPact, type LJM, P, PH, A, V, , UL listed, current limiting, Bolt-On, can used for 2P applications, complete with non-interchangeable micrologic standard 3.3 trip, trip functions and line side lug terminals, Solid State electronic, molded case circuit breakers
| Manufacturer | Square D | Subcategory | Molded Case |
| Family | PowerPact | Protection | Solid State |
| Connection | Bolt-On | ||
| Manufacturer | Square D | ||
| Subcategory | Molded Case | ||
| Family | PowerPact | ||
| Protection | Solid State | ||
| Connection | Bolt-On |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
We can test, inspect and repair your LJM36250U31X. All repairs include a 2-Year Electrical.com Warranty.
The Square D LJM36250U31X is a ‑pole, amp PowerPact® L‑Frame molded case circuit breaker from Schneider Electric’s Square D brand, engineered to provide high‑performance overcurrent protection in commercial and industrial power distribution systems. Rated for use up to 600 VAC, this breaker is suited for applications including feeder protection, main disconnect duty, and branch‑circuits in large panelboards and switchboards. Its PowerPact L frame construction delivers a rugged, compact design that balances high current capacity with space‑efficient installation.
Electrically, the LJM36250U31X features a MicroLogic 3.3 electronic trip unit with LI (long‑time and instantaneous) trip functions, providing dependable protection against overloads and short‑circuit events. It carries interrupting rating of {aic rating}, ensuring safe interruption of fault currents in industrial environments with substantial available fault energy. Rated at 80% continuous current, this breaker helps engineers meet coordination and selective protection requirements while minimizing nuisance trips.
Mechanically, the LJM36250U31X uses a unit‑mount, bolt‑on style connection with line‑side lugs and terminal‑nut load connections for secure, high‑current wiring. The breaker includes features such as dual‑break rotating contacts to reduce peak let‑through during faults and an integral push‑to‑trip button for manual testing and maintenance. Designed to comply with UL 489, CSA, NEMA, and IEC standards, this PowerPact breaker integrates seamlessly into industrial or commercial electrical systems, offering reliable performance and long‑term service life.
