W+200MLCFC
W+200MLCFC
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
W+200MLCFC Specifications
View Full SpecificationsView Specifications
W+200MLCFC, Cutler Hammer, Advantage Series, type W+200, 3P, 3PH, 27A, 600V, 1 hp @ 230V, 2 hp @ 460V, complete with 120V 60Hz, AC coil, AC non-reversing starter, NEMA size 1 suitable for use with Advantage Series motor control systems
| Manufacturer | Cutler Hammer | Subcategory | Motor Starter |
| Family | Advantage Series | ||
| Manufacturer | Cutler Hammer | ||
| Subcategory | Motor Starter | ||
| Family | Advantage Series |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
We can test, inspect and repair your W+200MLCFC. All repairs include a 2-Year Electrical.com Warranty.
The W+200MLCFC is a non-reversing NEMA magnetic motor starter from the Eaton Cutler-Hammer W200 series, designed for reliable three-phase motor control in commercial and industrial environments. This model features a 3-pole configuration, supports a lower range of NEMA Size 1, and is equipped with a 120VAC coil at 60Hz. It is rated for operation up to 600V AC and is intended for full-voltage, across-the-line starting and stopping. The starter provides standard overload protection and is supplied in an open style with no enclosure, making it suitable for integration into custom control panels or OEM assemblies. Maximum horsepower ratings include 1 HP at 200/230V AC, 1/4 to 2 HP at 460V AC, and 2 HP at 460/575V AC. The motor full load ampere (FLA) range is 0.47–3.81A (1.15–1.25 service factor) and 0.51–4.14A (1.0 service factor), making it ideal for small motor applications that require precise protection and control.
The W200 series, which includes the W+200MLCFC, is recognized for its robust NEMA-rated construction, compact Advantage Enhanced design, and straightforward integration with Eaton, Cutler-Hammer, and legacy Westinghouse control systems. Since its introduction, the series has been widely adopted for small motor loads in both new installations and retrofit projects, offering reliable phase loss, phase imbalance, and ground current protection. The W+200MLCFC is UL listed and designed for open-panel mounting, supporting a wide range of industrial automation and facility management requirements.
For applications that demand a compact, dependable starter for lower horsepower motors, the W+200MLCFC provides a proven platform with essential protection features and easy integration into existing systems. Electrical.com offers this model with technical documentation, configuration support, and expert assistance to ensure proper specification and seamless integration into your motor control architecture, supporting long-term operational reliability and safety.
