C25DNJ250A
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
C25DNJ250A Specifications
View Full SpecificationsView Specifications
C25DNJ250A, Cutler Hammer, Eaton, C25 Series, type C25, 2P, 1PH, 50A, 600V, Inductive Full Load 50A, Resistive 65A, Maximum Motor 3hp @ 1PH, complete with 110V-120V 50/60Hz, AC coil, lugs without quick connect terminals, (vertical in-line), open type definite purpose contactors with baseplate, suitable for use with Cutler Hammer definite purpose motor control systems
| Manufacturer | Eaton | Subcategory | Contactor |
| Family | C25 Series | ||
| Manufacturer | Eaton | ||
| Subcategory | Contactor | ||
| Family | C25 Series |
Electrical.com is NOT an authorized distributor for Eaton and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
C25DNJ250A Specifications:
Part NumberC25DNJ250A
Manufacturers
Sub-CategoryContactor
FamilyC25 Series
TypeC25
UPC782116300457
Weight2 lbs
GroupDefinite Purpose Contactor
Amperage50
Poles2
TerminalsBox lugs (posidrive setscrew) and quick connect terminals (vertical in-line)
Coil Voltage110-120 Vac, 50/60 Hz
Coil Voltage Min110
Voltage600
Starter TypeNon-Reversing
Enclosure TypeOpen with metal mounting plate
Coil Voltage Max120
Phase1
