C25FNF350B
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
C25FNF350B Specifications
View Full SpecificationsView Specifications
C25FNF350B, Cutler Hammer, Eaton, C25 Series, type C25, 3P, 3PH, 50A, 600V, 50A, complete with 208V-240V 50/60Hz, AC coil, box lugs with quick connect terminals (side-by-side), open type definite purpose contactors with metal mounting plate
| Manufacturer | Eaton | Subcategory | Contactor |
| Family | C25 Series | ||
| Manufacturer | Eaton | ||
| Subcategory | Contactor | ||
| Family | C25 Series |
Electrical.com is NOT an authorized distributor for Eaton and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
C25FNF350B Specifications:
Part NumberC25FNF350B
Manufacturers
Sub-CategoryContactor
FamilyC25 Series
TypeC25
UPC782113476087
Weight2.8 lbs
GroupDefinite Purpose Contactor
Amperage50
Poles3
TerminalsBox lugs (posidrive setscrew) and quick connect terminals (side-by-side)
Coil Voltage208-240 Vac, 50/60 Hz
Coil Voltage Min208
Voltage600
Starter TypeNon-Reversing
Enclosure TypeOpen with metal mounting plate
Coil Voltage Max240
Phase3
