CR306F002
CR306F002
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
CR306F002 Specifications
View Full SpecificationsView Specifications
CR306F002, General Electric, 300 Line, type CR306, 3P, 3PH, 135A, 600V, complete with 115V-120V 50/60Hz, AC coil, non-reversing, non-combination open type magnetic starter, NEMA size 4, suitable for use with CR306 motor control systems
| Manufacturer | General Electric | Subcategory | Motor Starter |
| Family | 300 Line | ||
| Manufacturer | General Electric | ||
| Subcategory | Motor Starter | ||
| Family | 300 Line |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
CR306F002 Specifications:
Part NumberCR306F002
Manufacturers
Sub-CategoryMotor Starter
Family300 Line
TypeCR306
UPC783166361672
Weight28 lbs
Amperage135
Poles3
NEMA Rating4
Coil Voltage Min115
Voltage600
Coil Voltage Max120
Phase3
