8536SDO1V02S
8536SDO1V02S
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
8536SDO1V02S Specifications
View Full SpecificationsView Specifications
8536SDO1V02S, Schneider Electric, Square D, Class 8536, motor starter, type S, 3P, 3PH, 45A, 600V with 120V 60Hz / 110V 50Hz coil, NEMA size 2, open type
| Manufacturer | Schneider Electric | Subcategory | Motor Starter |
| Family | Class 8536 | ||
| Manufacturer | Schneider Electric | ||
| Subcategory | Motor Starter | ||
| Family | Class 8536 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
We can test, inspect and repair your 8536SDO1V02S. All repairs include a 2-Year Electrical.com Warranty.
The 8536SDO1V02S is a NEMA motor starter from the Square D Type S series, engineered for full-voltage starting and stopping of AC squirrel cage motors in commercial and industrial settings. The 8536SDO1V02S features a 3-pole configuration, a 45A current rating, and is rated for operation up to 600V AC. This Size 2, non-reversing starter is equipped with a melting alloy thermal overload relay and a 120V AC coil (110V at 50 Hz, 120V at 60 Hz). The 8536SDO1V02S offers a short-circuit current rating ({aic rating}) of 5kA at 600V AC and is designed for open, surface mounting with screw clamp terminals for secure wiring connections.
The Type S series, which includes the 8536SDO1V02S, is known for its robust construction, flexible overload relay options, and compatibility with a variety of Square D motor control systems. Since its introduction, this series has been widely used for reliable motor control, supporting a range of horsepower ratings—up to 10 HP at 200V AC, 15 HP at 230V AC, and 25 HP at 460/575V AC for this model. The 8536SDO1V02S is UL listed and CSA certified, meeting NEMA standards for dependable operation in demanding environments.
For facilities requiring dependable motor control, the 8536SDO1V02S provides a field-proven solution with easily replaceable components and a design that supports straightforward installation and maintenance. Electrical.com’s technical team can assist with application engineering, troubleshooting, and ensuring the 8536SDO1V02S is properly specified for your project’s requirements, helping you maintain operational reliability and safety in your motor control systems.
