LRD01
LRD01
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
LRD01 Specifications
View Full SpecificationsView Specifications
LRD01, Schneider Electric, Telemecanique, TeSys D, Class 10 bimetallic Thermal overload relay, type LRD, 3P, rated for 0.1 - 0.16A, 600V, suitable for use with LC1D09,LC1D12,LC1D18,LC1D25,LC1D32,LC1D38 contactors
| Manufacturer | Schneider Electric | Subcategory | Overload Relay |
| Family | TeSys D | ||
| Manufacturer | Schneider Electric | ||
| Subcategory | Overload Relay | ||
| Family | TeSys D |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
We can test, inspect and repair your LRD01. All repairs include a 2-Year Electrical.com Warranty.
The Schneider Electric LRD01 is a Thermal overload relay from the TeSys D series, designed to provide reliable motor protection in industrial motor control applications. This Class 10 relay features adjustable trip settings with a range of 0.1-0.16A, ideal for safeguarding motors from overloads and phase loss.
Built to integrate with Schneider Electric TeSys contactors, the LRD01 supports direct mounting to models: LC1D09,LC1D12,LC1D18,LC1D25,LC1D32,LC1D38. Its robust design ensures long operational life and precision protection in both light and heavy-duty environments. The relay includes manual and automatic reset modes, stop button, and trip indicator for easy diagnostics and control.
You can find the LRD01 at Electrical.com, your reliable partner for Schneider Electric and Telemecanique contactors, thermal overload relays, motor starters and industrial control products. Our dedicated sales team is ready to assist with technical questions, product selection, and support.
