LRD22 Schneider Electric Overload Relay Motor Control

LRD22

Schneider Electric - Overload Relay

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

LRD22 Specifications

View Full SpecificationsView Specifications

LRD22, Schneider Electric, Telemecanique, TeSys D, Class 10 bimetallic Thermal overload relay, type LRD, 3P, rated for 16 - 24A, 600V, suitable for use with LC1D25,LC1D32 contactors

Manufacturer	Schneider Electric	Subcategory	Overload Relay
Family	TeSys D
Manufacturer	Schneider Electric
Subcategory	Overload Relay
Family	TeSys D

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

LRD22 Specifications:

Part NumberLRD22

Manufacturers

Schneider Electric, Telemecanique

Sub-CategoryOverload Relay

Other NamesLRD-22

FamilyTeSys D

TypeLRD

Suitable ForLC1D25,LC1D32

Relay StyleThermal

Amperage Min16

Amperage Max24

Additional Information

Electrical.com 2 Year warranty
Shipping Options
Return Policy

Similar Products

Need A Repair?

We can test, inspect and repair your LRD22. All repairs include a 2-Year Electrical.com Warranty.

To receive a repair quote, complete the repair form or call our expert sales team for an instant quote.

Call: 877-999-7077orFill Out A Repair Form

The Schneider Electric LRD22 is a Thermal overload relay from the TeSys D series, designed to provide reliable motor protection in industrial motor control applications. This Class 10 relay features adjustable trip settings with a range of 16-24A, ideal for safeguarding motors from overloads and phase loss.

Built to integrate with Schneider Electric TeSys contactors, the LRD22 supports direct mounting to models: LC1D25,LC1D32. Its robust design ensures long operational life and precision protection in both light and heavy-duty environments. The relay includes manual and automatic reset modes, stop button, and trip indicator for easy diagnostics and control.
