SEHF362000LSIES9C8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 2000A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 125VDC spring charging motor, shunt closing coil & 24VDC shunt trip along with 2 N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

HDA261502AEBCUDYP, Square D, PowerPact, type , 1PH, 2P, A & C phase connection, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch, 208/277 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

MDN4083LEA0522NMNH2NNRNPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 250A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 48Vdc UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

PEF36800, Square D, Micrologic, type , 3P, 3PH, 800A, 600V, 100kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with Micrologic non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and rating plug, lugs not included, Solid State electronic, molded case circuit breakers

SSF1G3J1J, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LI - Long-Time and Instantaneous trip functions, full metering, modbus communication and relays features and 500A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

WLL3D350UR, Siemens, WL Series, type , frame size III, drawout, 3P, 3PH, 5000A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU755 programmer, LSI - Long-Time, Short-Time and Instantaneous trip functions and 2000A rating plug, Solid State electronic, low voltage insulated case circuit breakers

HRM36100CU43X, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 100A, 600V, 200kA@480V, current limiting, Bolt-On, 100% rated, UL listed, suitable for reverse fed applications, complete with micrologic ammeter 5.2A non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, line side lug terminals, Solid State electronic, molded case circuit breakers

HDA36150U43XAEBCSD, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 5.2A non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, complete with 1A/1B low-level aux switch, alarm switch, 208/277 VAC shunt trip, molded case circuit breakers

HGA36110AEBEUPYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 110A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, 48 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

OHG125J10, ABB, SACE Isomax, variable depth rotary handle, 4.9

PDG23P0100D2MN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 100A, 100kA@480V, Bolt-On, no lug terminals, complete with Xpert Release PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, relays and modbus, Solid State electronic, molded case circuit breakers; globally rated

HLD26025C, Schneider Electric, Square D, PowerPact, type , 2P, 1PH, 25A, 600V, 100kA@480V, UL listed, current limiting, Draw-Out, 100% rated, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

SEHF361800LSES5C4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 1800A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LS - Long-Time and Short-Time trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 24VDC shunt trip along with 2 N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

N22P23036B6, General Electric, Bolt for Charging Handle, qty 1 needed per breaker, suitable for use with WPS08, WPF08, WPH08, WPX08, WPS16, WPF16, WPH16, WPS20 air circuit breakers

MDN4083LEA0222NMNH4YCNCSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB metal frame padlockable pushbutton cover, 3P, 3PH, 800A, 200A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 48Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 4A/4B auxiliary switch, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

1371D39G03, Cutler Hammer, Eaton, SELTRONIC, type , auxiliary, 1 auxiliary switch attachment kit for field mounting, left pole mounted, 18 inch lead connection, 1A/1B, rated for 480Vac, suitable for use with NC,NCA,NCG,NCGA,HNC,HNCA,HNCG,HNCGA frame molded case circuit breakers with solid-state trip units

FAL340701388, Square D, FAL Series, type , 3P, 3PH, 70A, 480V, 18kA@480V, standard interrupting capacity, Feed-Thru, complete with 277/480Vac shunt trip and 1A/1B aux switch, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

SEHF36800ES8D4, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 800A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 24VDC shunt closing coil & 24VDC shunt trip along with 2A2B with 1N.O./N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

LAF-800A-EO-DO-LIG, Siemens-Allis, LA Series, type , 800A frame size, NEMA class J or L integrally-mounted current limiting fuses, electrically operated/Draw-Out, 3P, 3PH, 80-800A current sensor rating, 600V, 200kA@480V, originally supplied with StaticTrip II or LimiTrip overcurrent trip devices but can also be retrofitted with a modern Solid State electronic trip unit with LIG - Long-Time, Instantaneous and Ground Fault trip functions, low voltage power air circuit breakers

MDN4083LEA0322NMNH4YNYCAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 48Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

HDA261502AABKYP, Square D, PowerPact, type , 1PH, 2P, A & C phase connection, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, low-level, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDL26100ABBHURYP, Square D, PowerPact, type , 2P, 1PH, 100A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch low-level, 125 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

GJS410035M, Cutler Hammer, Series G, type , 4P, 3PH, 100A, 600V, 35kA@480V, high interrupting capacity, Bolt-On, complete breaker with 310+ electronic, interchangeable trip unit, metric end caps, Solid State, molded case circuit breakers

JGC3250AAGH08, Cutler Hammer, Series G, Type , 3P, 3PH, 250A, 600V, 100kA@480V, current limiting, UL listed for Marine applications 40°C, Feed-Thru, complete with interchangeable trip unit and line & load side lug terminals, Thermal Magnetic molded case circuit breakers
