MEL36175LSA, Square D, Micrologic, type , 3P, 3PH, 175A, 600V, 65kA@480V, high interrupting capacity, Feed-Thru, 100% rated, complete with full function Micrologic non-interchangeable trip, LSGA - Long-Time, Short-Time and Ground Fault Alarm trip functions, ARP070 installed rating plug and line & load side lug terminals, Solid State electronic, molded case circuit breakers

E2M3600TN, Cutler Hammer, Series C, trip units and programmers, type , 3P, interchangeable trip, LI - Long-Time and Instantaneous trip functions, rated for 600A, magnetic trip range 1500-3000A, suitable for 800A- E2M,E2MM mining service molded case circuit breaker frame types, Thermal Magnetic trip units & circuit breakers

HDA36020BEUK, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 20A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 24 VAC under voltage release (UVR), molded case circuit breakers

KXT5DWFPEF6-4, ABB, SACE Tmax XT, fixed part of withdrawable circuit breaker, with extended front terminals, suitable for use with 4P type 630A XT5 circuit breakers; 1SDA104693R1 global reference

SEF361000ES7D4, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 1000A, 600V, 100kA@480V, Bolt-On, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 125VDC shunt trip along with 2A2B with 1N.O./N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

HMCP007C0S21, Cutler Hammer, Westinghouse, Eaton, Series C, type , F Frame, 3P, 3PH, 7A, 600V, 65kA@480V, Feed-Thru, complete with right-pole mounted 48-127Vac 48-60Vdc right side shunt trip, non-interchangeable trip with I - Instantaneous Protection Only, standard line & load side lug terminals, MCP, motor circuit protector, magnetic range 21-70A, motor FLA 1.5-5.7A, Magnetic Only, molded case circuit breakers

HLA36150U31XABBCUP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B aux switch, alarm switch, 48 VDC under voltage release (UVR), molded case circuit breakers

PDF33FH400B2NN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 400A, High Override, 25kA@480V, 100% UL, Bolt-On, no lug terminals, complete with PXR10 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

HJL36090AABKUK, Square D, PowerPact, type , 3P, 3PH, 90A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, low-level, 24 VAC under voltage release (UVR), molded case circuit breakers

SEHF36400LSGES6, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 400A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 48VDC shunt trip, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PJF36025U41BRE10, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 250A, 600V, 65kA@480V, UL listed, high interrupting capacity, Bolt-On, complete with door mounted standard black handle, micrologic interchangeable ammeter 3.0A trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Solid State electronic, molded case circuit breakers

DS206E-400A-MO-DO-LIG, Cutler Hammer, DS Series, type , 800A frame size, 50-800A trip range, manually operated/Draw-Out, 3P, 3PH, 400A current sensor rating, 600V, 65kA@480V, extra interrupting, available with solid state trip unit, Solid State electronic, air circuit breakers

LDK3K060L, Siemens, VL Series, type , DG frame, 3P, 3PH, 60A, 600V, 100kA@480V, very high interrupting capacity, 40°C, Feed-Thru, LCD trip unit, LSI - Long-Time, Short-Time and Instantaneous trip functions + GF alarm, line & load side lug terminals, Solid State electronic, molded case circuit breakers

SGHA26AT4300C, General Electric, Spectra Series, type , 2P, 1PH, 300A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, complete with SRPG400A300 rating plug, suitable for reverse fed applications, UL listed, complete with interchangeable RMS trip unit with LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

MP12H2-3P-1000A-EO-BO-LI, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 1200A frame, includes 1200A sensor rating with 1000A rating plug, 3P, 3PH, 600V, 100kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

HLA36070ABBKSD, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 70A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, low-level, 208/277 VAC shunt trip, molded case circuit breakers

HGA36100AAUSYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 100A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, 250 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

MDN4083LEA0122NMNE2NNKNPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-125Vdc UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Kirk keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

LV432855, Schneider Electric, Compact, Ammeters, 630A ammeter module, 3 pole, suitable for use with Compact NSX 630A type molded case circuit breakers

HGA36150U43XAAYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 5.2A non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, complete with 1A/1B aux switch, "ON" or "OFF" end handle padlock device, molded case circuit breakers

NJHF36600E53, Schneider Electric, Square D, Merlin Gerin, Compact, type , 3P, 3PH, 600A, 600V, 65kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with STR53UP-F trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs not included, Solid State electronic, molded case circuit breakers

HGL36020BKUA, Square D, PowerPact, type , 3P, 3PH, 20A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, low-level, 120 VAC under voltage release (UVR), molded case circuit breakers

HGL26125AESJYP, Square D, PowerPact, type , 2P, 1PH, 125A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B low-level aux switch, 525/600 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

TEL134070KIL General Electric TEL Series, type , 3P, 3PH, 70A, 480V, 65kA@480V, high interrupting capacity, Bolt-On, complete with mechanical key interlock, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers
