BDA34045Y, Schneider Electric, Square D, PowerPact, type , 3PH, 3P, 480Y/277Vac, 45A, 18kA@480V rated, I-Line Style Plug-In with ABC phase connection, complete with non-interchangeable trip rated 480Y/277V max, LI - Long-Time and Instantaneous trip functions and load side mechanical lug terminals, Thermal Magnetic, molded case circuit breakers

HDA261254, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 125A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HDA261104, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 110A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

LRL36600U33X, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 600A, 600V, 200kA@480V, UL listed, current limiting, Feed-Thru, can used for 2P applications, complete with non-interchangeable micrologic standard 3.3S trip unit, LSI - Long-Time, Short-Time and Instantaneous trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

KHL3625025DC, Square D, KHL Series, type , 3P, 3PH, 250A, 600Vdc, DC rated, 20kA@500V, high interrupting capacity, Feed-Thru, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

FA11027, Square D, Square D Series, type , shunt trip, 24VDC, when installed in a circuit breaker the part number suffix is -1027, suitable for use with FA,FAF,FAL,FAP,FH,FHF,FHL,FHP circuit breaker frame types

KA11127, Square D, Square D Series, type , under voltage release, 24VDC, (1) undervoltage trip, when installed in a circuit breaker the part number suffix is -1127, suitable for use with KA,KAF,KAL,KAP,KH,KHF,KHL,KHP frame molded case circuit breakers

STR58U-LSIG, Merlin Gerin, Schneider Electric, Square D, Masterpact, trip units and programmers/programmers, suitable for use with type M,MP, 3P or 4P, 800A - 6300A, 600V, insulated case circuit breakers, Solid State electronic protection, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, these trip unit devices are now obsolete; however, we do still stock them and we offer modern day direct replacement programmers for this model

HDA260801, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 80A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers

QOM2175MM, Square D, QOM Series, type , 2P, 1PH, 175A, 120/240V, 10kA@240V, suitable for use as bolt-in main breaker in 200A max type MP, MPR and MPH METER-PAK metering equipment, standard interrupting capacity, 40°C, Bolt-On, Thermal Magnetic molded case circuit breakers

S48820, Square D, Schneider Electric, PowerPact, adjustable rating plug element, factory-installed breaker suffix "C", suitable for use with Powerpact & Masterpact - PG,PJ,PK,PL,RG,RJ,RK,RL,NT,NW molded case circuit breaker frame types, for use with Micrologic solid state electronic trip units & circuit breakers

KA11021, Square D, Square D Series, type , shunt trip, 240/240V, when installed in a circuit breaker the part number suffix is -1021, suitable for use with KA,KAF,KAL,KAP,KH,KHF,KHL,KHP circuit breaker frame types

FGA240304, Square D, Schneider Electric, PowerPact, type , 2P, 1PH, 30A, 277/480V, 35kA@480V, B & C phase circuit configuration, high interrupting capacity, 40°C, I-Line Style Plug-In, Thermal Magnetic, molded case circuit breakers

EDB36045, Schneider Electric, Square D, EDB Series, type , 3P, 3PH, 45A, 600V, 18kA@480V, standard interrupting capacity, 40?C, Bolt-On, Thermal Magnetic, molded case circuit breakers

LDA36400U43X, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 400A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, can used for 2P applications, complete with non-interchangeable micrologic ammeter 5.3A trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers

JDA262004, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 200A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

KH361751021, Square D, I-Line, Type , 3P, 3PH, 175A, 600V, 35kA@480V, high interrupting capacity, 40°C, complete with 120/240 Vac shunt trip, I-Line Style Plug-In, Thermal Magnetic molded case circuit breakers

S29340, Square D, PowerPact, rotary , door mounted, handle only, red handle on yellow bezel, suitable for use with H- and J-Frame HDL, HDF, HDM, HDP, HDA, HDN, HDD, HDS, HGL, HGF, HGM, HGP, HGA, HGN, HGD, HGS, HJL, HJF, HJM, HJP, HJN, HJD, HJS, HJA, HLL, HLF, HLM, HLP, HLA, HLD, HLN, HLS, JDL, JDF, JDM, JDP, JDA, JDN, JDS, JGL, JGF, JGM, JGP, JGA, JGD, JDS, JDN, JJL, JJF, JJM, JJP, JJA, JJN, JJD, JJS, JLL, JLF, JLM, JLP, JLA, JLN, JLD, JLS, JRA, JRF, JRL, JRM, JRP, JRN, JRD, JRS {Suitable For} type molded case circuit breakers

PXF361600PL, Square D, Micrologic, type , 3P, 3PH, 1600A, 600V, 100kA@480V, high interrupting capacity, Bolt-On, complete with Micrologic non-interchangeable trip and padlock handle, LSI - Long-Time, Short-Time and Instantaneous standard trip functions and rating plug, lugs not included, Solid State electronic, molded case circuit breakers

EJB14030EPD, Schneider Electric, Square D, EJB Series, type , 1P, 1PH, 30A, 277V, 65kA@480V, extra high interrupting capacity, 40°C, Bolt-On, LI - Long-Time and Instantaneous trip functions, includes equipment protection device, Thermal Magnetic molded case circuit breakers

HDA360706, Square D, PowerPact, type , 3PH, 3P, CBA phase connection, 70A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers
