HDA36125AFSH, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 125A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, 380/480 VAC shunt trip, molded case circuit breakers

PDG33N0600D4ML, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 600A, 85kA@480V, Bolt-On, load side lug terminals, complete with PXR20D ARMS trip with LSI - Long-Time, Short-Time and Instantaneous trip functions and Modbus RTU & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

ME36800LSG2200, Square D, I-Line, type , 3P, 3PH, 800A, 600V, 65kA@480V, high interrupting capacity, I-Line Style Plug-In, 100% rated, complete with shunt trip and alarm contact, full function Micrologic non-interchangeable trip, LSG - Long-Time, Short-Time and Ground Fault trip functions and , Solid State electronic, molded case circuit breakers

XT4HU3025MFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 3-Pole, 25A, 600V, 25kA@600V, Motor Circuit Protector (MCP), UL Standard, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No - 1SDA07211R1 global reference

HDA36030UP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 30A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 48 VDC under voltage release (UVR), molded case circuit breakers

PEF362500, Square D, Micrologic, type , 3P, 3PH, 2500A, 600V, 100kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with Micrologic non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and rating plug, lugs not included, Solid State electronic, molded case circuit breakers

CP3-T800, ITE, Cordon, type , interchangeable trip unit with LI - Long-Time and Instantaneous trip functions, rated for 800A, suitable for 1600A- CP Cordon molded case circuit breaker frame types, Thermal Magnetic trip units and programmers & circuit breakers; these trip units are obsolete; however we do still stock them

MP20-3P-1000A-EO-BO-LSIG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 2000A frame includes 1200A, 1600A or 2000A sensor rating with 1000A rating plug, 3P, 3PH, 600V, 50kA@480V, accepts the following programmers/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

LCV-FUSE-TRUCK-2000A, Toshiba, LCV Series, , 3PH, 3P, 5000 VAC, 2000 Frame, NA, Draw-Out, Medium Voltage air circuit breaker, For Use In Switchgear. Operating Voltage, Control Voltages, Wiring, and Additional Accessories to be determined before ordering.

PDG24P0100P2DN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 100A, 100kA@480V, Bolt-On, no lug terminals, complete with Xpert Release PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, relays, modbus and CAM, Solid State electronic, molded case circuit breakers; globally rated

HJL36100M73BHURYP, Square D, PowerPact, type , 3P, 3PH, 100A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, I - Instantaneous protection only and line & load side lug terminals, MCP, motor circuit protector, magnetic range 180-1040A, Magnetic Only, complete with alarm switch low-level, 125 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

FAF12030V, Square D, FAF Series, type , 1P, 1PH, 30A, 240V, 10kA@240V, standard interrupting capacity, Bolt-On, complete with visi-trip window, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic molded case circuit breakers

BE-685686, BRAH Electric, Masterpact, substitute under voltage release, , 440/480VAC 50/60Hz, suitable for use with MP frame insulated case circuit breakers

LA2200S, Westinghouse, LA Series, type , 2P, 1PH, 200A, 600V, 30kA@480V, standard interrupting capacity, Bolt-On, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, Saf-T-Vue window and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

HFWF3063L, Cutler Hammer, Westinghouse, Eaton, Series C, type , 3P, 3PH, 63A, 690V, 70kA@415V, high interrupting capacity, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

LCG3225, Westinghouse, SELTRONIC, type , 3P, 3PH, 225A, 600V, 30kA@480V, standard interrupting capacity, Bolt-On, complete with 3LCG225 - 225A rating plug, complete with LSG - Long-Time, Short-Time and Ground Fault trip functions, complete with load side lug terminals, Solid State electronic molded case circuit breakers; these breakers are obsolete, however we do still stock them

HJL36030BESLYP, Square D, PowerPact, type , 3P, 3PH, 30A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HGL26060AFBKSKYP, Square D, PowerPact, type , 2P, 1PH, 60A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG23F0060E2RJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 60A, 25kA@480V, Feed-Thru, line & load side lug terminals, complete with Xpert Release PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions and relays, Solid State electronic, molded case circuit breakers; globally rated

C01FD62, Siemens, SENTRON, type , bell alarm, 1 alarm switch and 1 auxiliary switch, rated for VAC/250VDC, suitable for use with FD,HFD,HHFD,FXD,HFXD,HHFXD,CFD,FM6B,FMKB frame molded case circuit breakers

PDG34KH400D5YK, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 400A, High Override, 50kA@480V, Bolt-On, line side lug terminals, complete with PXR20D trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and Modbus RTU, CAM Link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

HDA260401ABSJ, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 40A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, 525/600 VAC shunt trip, molded case circuit breakers

HJH4C300, Siemens, VL Series, Type , 4P, 3PH, 300A, 600V, 65kA@480V, high interrupting capacity, 50°C, Bolt-On, 100% rated, complete with interchangeable trip unit, lugs not included, Thermal Magnetic molded case circuit breakers

HDA36020ABBEUAYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 20A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, 120 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers
