HGA260904AABCUHYP, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 90A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch, 380/480 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

HLA36050AFBKUD, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 50A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 208/277 VAC under voltage release (UVR), molded case circuit breakers

HDA260501ABBKUHYP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 50A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, low-level, 380/480 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

XT2LQ3100QFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 3-Pole, 100A, 600V, 35kA@600V, Ekip Touch LSIG, UL 100% Rated, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No

CKIXFE36080LI, Merlin Gerin, Square D, Schneider Electric, Compact, type , 3P, 3PH, 800A, IEC rated, 660/690V, 150kA@415V, very high interrupting capacity, Bolt-On, complete with STR25DP trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Solid State electronic molded case circuit breakers

HGA36060U43XAFBCUAYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 60A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 5.2A non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, alarm switch, 120 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

MP08-3P-125A-MO-DO-LSG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 800A frame with 250A trip and 125A rating plug, 3P, 3PH, 600V, 50kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

HGA36100U44XAABHUH, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 100A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 6.2A non-interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, complete with 1A/1B aux switch, alarm switch low-level, 380/480 VAC under voltage release (UVR), molded case circuit breakers

PDG54N0800D4MN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 800A, 85kA@480V, Bolt-On, no terminals, complete with PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous with ARMS trip functions with relays and modbus option, Solid State electronic, molded case circuit breakers; globally rated

HDA36080ABBESLYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 80A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

NNY4P120, Siemens, VL Series, type , NG Frame, 4P, 3PH, 1200A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, 100% rated, suitable for reverse feed applications, complete with non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs not included, Digital Solid State Electronic molded case circuit breakers

HLA36060BCSVYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 60A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch, 60 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HFDDC1100L, Westinghouse, Eaton, Cutler Hammer, Series C, type , 1P, 1PH, 100A, 600V, DC rated, 42kA@600V, high interrupting capacity, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

HGL26060AFBHSRYP, Square D, PowerPact, type , 2P, 1PH, 60A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch low-level, 125 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG34G0400E5XJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 400A, 35kA@480V, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with CAM link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PVV-1200-2000-1200A-MO-6P, General Electric, PowerVac, , Manually Operated, 3PH, 6 Bushing Design, 15000 VAC, 1200A Frame, circuit breaker ground & test device, For Use In PowerVac Switchgear. Available in 3 or 6 pole bushing design, multiple cable connection styles, combination amperages (1200/2000/3000), electrically operated or manually operated, upon request. Additional Accessories including Grounding Cable Sets to be determined before ordering.

PJF36040U44A, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 400A, 600V, 65kA@480V, UL listed, high interrupting capacity, Bolt-On, complete with micrologic interchangeable ammeter 6.0A trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, lugs not included, Solid State electronic, molded case circuit breakers

RD325T82W, Westinghouse, Cutler Hammer, Eaton, Series C, type , 3P, 3PH, 2500A, 600V, 65kA@480V, standard interrupting capacity, 40°C, Bolt-On, complete with interchangeable LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs and rating plug not included, Digitrip RMS 810 Solid State Electronic molded case circuit breakers

MGN61329, Schneider Electric, Square D, Multi9, type , UL listed, CSA certified, 3P, 3PH, 8A, 480V, 10kA@480V, standard interrupting capacity, Feed-Thru, C Curve 7-10 x ampere rating (7-14 for DC), single-barrel wire lug, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case miniature circuit breakers, suitable for reverse feeding

PDG24F0060D3WJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 60A, 25kA@480V, Feed-Thru, line & load side lug terminals, complete with Xpert Release PXR20D trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, relays, modbus, CAM and ZSI, Solid State electronic, molded case circuit breakers; globally rated

HDA260301AFBCSL, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 30A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch, 48 VAC shunt trip, molded case circuit breakers

HGA260205UO, Square D, PowerPact, type , 1PH, 2P, C & A phase connection, 20A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 24 VDC under voltage release (UVR), molded case circuit breakers

XSUCCFAZZAAAA00000, ABB, SACE Tmax XT, type , 3PH, 3P, 600V, 800A, 50kA@480V, Bolt-On, front terminals, complete with Ekip trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, Thermal Magnetic, distribution circuit breakers; 1SDA103352R1 global reference

HDA260201ABBESLYP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 20A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers
