SED36200LIGES6D8, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 200A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LIG - Long-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 48VDC shunt trip along with 4A4B with 1N.O./N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDG32K0400P4YN, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 400A, 50kA@480V, Bolt-On, no lug terminals, complete with PXR25 trip with ARMS LSI - Long-Time, Short-Time and Instantaneous trip functions with Modbus RTU, CAM link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

HJA36125AESR, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 125A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, 125 VDC shunt trip, molded case circuit breakers

SSD1G1Y8C, General Electric, Power Break II, type , 3P, 3PH, 600V, 200A current sensor rating, 65kA@480V, standard interrupting capacity, Draw-Out, 800A frame, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, full metering, modbus communication, relays & ZSI features and 200A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

HLA36070AFBEUP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 70A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, 48 VDC under voltage release (UVR), molded case circuit breakers

PKL36120CU63AE1AA, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1200A, 600V, 50kA@480V, UL listed, high interrupting capacity, Feed-Thru, 100% rated, complete with 1A/1B auxiliary switch, micrologic interchangeable power 5.0P trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

XT5LQ440AYFF000XXX, ABB, SACE Tmax XT, type , UL 100% rated, 3PH, 4P, 600V, 400A, 100kA@480V, Bolt-On, front terminals, complete with Ekip G Touch LSIG trip, generator protection circuit breakers; 1SDA102697R1 + 1SDA102826R1 + 1SDA112974R1 global reference

WLL1D312NH, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 1200A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU745 programmer + WLLCD48 LCD display + WLGFM48 ground fault module, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and 800A rating plug, Solid State electronic, low voltage insulated case circuit breakers

PDF33MH250E3ZJ, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 250A, High Override, 65kA@480V, 100% UL, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

GRC320T32WP11, Cutler Hammer, Series G, type , 2000A frame, 3P, 3PH, 600V, 100kA@480V, very high interrupting capacity, Bolt-On, complete with Digitrip RMS 310 trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, 1600A fixed rating plug, Solid State electronic, molded case circuit breakers

HDA260201BHUR, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 20A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with alarm switch low-level, 125 VDC under voltage release (UVR), molded case circuit breakers

PDG34GH400E3WN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 400A, High Override, 35kA@480V, Bolt-On, no lug terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

E2F3025, Eaton, Cutler Hammer, Westinghouse, Series C, E2 mining service breakers, type , 3P, 3PH, 25A, 600V, 250Vdc, 18kA@600V, standard interrupting capacity, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

SSB4G4A7N, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, back connected, 2500A frame rating, complete with Entelliguard trip, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault trip functions, current metering & RELT features and 800A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

WLL1D312EB, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 1200A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU727 programmer, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and 315A rating plug, Solid State electronic, low voltage insulated case circuit breakers

MDN4083LEA0822NMNG4NNLMPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 32Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Castell key interlock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

PJD36025U44AAC, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 250A, 600V, 65kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with 3A/3B auxiliary switch, micrologic interchangeable ammeter 6.0A trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers

SSB4G4N3P, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, back connected, 2500A frame rating, complete with Entelliguard trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, current metering, modbus communication & ZSI features and 1000A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PLA34060SA, Square D, Schneider Electric, PowerPact, type , 3P, ABC phase connection, 3PH, 600A, 480V, 100kA@480V, UL listed, extra high interrupting capacity, I-Line Style Plug-In, complete with 110/130Vac shunt trip, basic non-interchangeable ET 1.0I trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers

WLC3F350NA, Siemens, WL Series, type , frame size III, fixed mount, 3P, 3PH, 5000A, 600V, 150kA@480V, UL listed, very high interrupting capacity, Bolt-On, complete with solid state ETU725 programmer with LSI - Long-Time, Short-Time and Instantaneous trip functions and 800A rating plug, Solid State electronic, low voltage insulated case circuit breakers

KXT5AUXCDQ3YW, ABB, SACE Tmax XT, cabled auxiliary contact, 3Q + 1SY 24 V DC, suitable for use with withdrawable XT5 molded case circuit breakers; 1SDA104797R1 global reference

JB3125V, Westinghouse, AB DE-ION, type , 3P, 3PH, 125A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, 50°C, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

PJA36080U44AE1YP, Square D, Schneider Electric, PowerPact, type , 3P, ABC phase connection, 3PH, 800A, 600V, 65kA@480V, UL listed, high interrupting capacity, I-Line Style Plug-In, complete with fixed handle padlocking device, modbus communications, micrologic interchangeable ammeter 6.0A trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers

FGA240905, Square D, Schneider Electric, PowerPact, type , 2P, 1PH, 90A, 277/480V, 35kA@480V, C & A phase circuit configuration, high interrupting capacity, 40°C, I-Line Style Plug-In, Thermal Magnetic, molded case circuit breakers
