PDG22P0030TFFK, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 30A, 100kA@480V, Bolt-On, line side terminals only, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PDG33M0250P2DN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 250A, 65kA@480V, Bolt-On, no lug terminals, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions with MODBUS RTU, CAM link & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

MP12H2-3P-1200A-EO-DO-LSIG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 1200A frame, includes 1200A sensor rating with 1200A rating plug, 3P, 3PH, 600V, 100kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

HLA36060AFBHUS, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 60A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch low-level, 250 VDC under voltage release (UVR), molded case circuit breakers

HJL36125BHSLYP, Square D, PowerPact, type , 3P, 3PH, 125A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch low-level, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDA36150U31XAFUD, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, 208/277 VAC under voltage release (UVR), molded case circuit breakers

TFK236100MH General Electric F225 Line, Type TFK, 3P, 3PH, 100A, 600V, 22kA@480V, complete with mechanical handle plate, load side lug terminals and interchangeable trip unit, standard interrupting capacity, 40ºC, Bolt-On, Thermal Magnetic molded case circuit breakers

HDA36150U31XAESRYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 1A/1B low-level aux switch, 125 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG44M0800VFAL, Eaton, Cutler Hammer, Power Defense, type , 50º C non-UL listed, 3PH, 4P, 100% neutral, 600V, 800A, 65kA@480V, Bolt-On, load side lug terminals, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; globally rated non-UL listed

PDG6XPXR42500E4Z, Eaton, Cutler Hammer, Power Defense, Power Xpert Release (PXR) trip units and programmers, 4P, 600V, 2500A, Solid State protection, PXR20 with LSI - Long-Time, Short-Time and Instantaneous trip functions with ARMS, relays and ZSI options, suitable for globally rated PDG,PDF Frame 6 circuit breakers

HJA260204AEBKUAYP, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 20A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 120 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

PLM34060U33A, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 600A, 480V, 100kA@480V, UL listed, extra high interrupting capacity, Bolt-On, complete with micrologic interchangeable standard 5.0 trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and line side lug terminals, Solid State electronic, molded case circuit breakers

CRD316T96W, Westinghouse, Cutler Hammer, Eaton, Series C, type , 3P, 3PH, 1600A, 600V, 65kA@480V, standard interrupting capacity, Bolt-On, 100% rated, complete with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, lugs and rating plug not included, Digitrip RMS 910 Solid State electronic, molded case circuit breakers

XT5NU325AWFF000XXX, ABB, SACE Tmax XT, type , 3PH, 3P, 600V, 250A, 35kA@480V, , front terminals, complete with Ekip M Touch with LRIU trip functions, Ekip M Touch LRIU electronic, molded case circuit breakers; 1SDA102469R1 global reference

KHL36090G, Square D, KHL Series, type , 3P, 3PH, 90A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

HDA36150BHSD, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch low-level, 208/277 VAC shunt trip, molded case circuit breakers

PDD22K0040VFFN, Eaton, Cutler Hammer, Power Defense, type , 50ºC, 1PH, 2P, 240V, 40A, 85kA@240V, Bolt-On, lugs not included, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; IEC certification; non-UL listed

HJA36150ABUO, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 150A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, 24 VDC under voltage release (UVR), molded case circuit breakers

HGA36020ABBHUAYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 20A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch low-level, 120 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG23M0060E2NN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 60A, 65kA@480V, Bolt-On, no lug terminals, complete with Xpert Release PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers; globally rated

HGL26070AABKSRYP, Square D, PowerPact, type , 2P, 1PH, 70A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, low-level, 125 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

Q160HH00S01 Siemens Q Series, type , 1P, 1PH, 60A, 120V, with factory installed 120V shunt trip, 65kA@120V, very high interrupting capacity, Plug-In, Thermal Magnetic molded case circuit breakers

TJD434400WL, General Electric, molded case Non-Automatic switch, 3P, 480V, 400A

MAL364001027, Square D, MAL Series, type , 3P, 3PH, 400A, 600V, 30kA@480V, standard interrupting capacity, Feed-Thru, complete with 24Vdc shunt trip, non-interchangeable trip LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers
