PEAL4ATTN0050, General Electric, GuardEon, type , 3PH, 4P, 600V, 50A, 150kA@480V, factory set to 100% neutral protection, front connection/Feed-Thru, toggle mechanism, complete with LTM interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; meet UL, cUL, IEC, CE, CCC requirements

PDG54M0800D2MM, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 800A, 65kA@480V, Bolt-On, no terminals with metric tapped conductors, complete with PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous trip functions with relays and modbus option, Solid State electronic, molded case circuit breakers; globally rated

SBA2016, Siemens, SB Series, type , 3P, 3PH, 2000A frame, rated for 1600A max, 600V, 65kA@480V, alternate interrupting rating, Bolt-On, Solid State electronic, insulated case circuit breakers

SHD1G2C1E, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 800A frame rating, complete with Entelliguard trip, LI - Long-Time and Instantaneous trip functions, current metering & modbus communication features and 250A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

LKD-16-MO-DO-LS, ABB, BBC, ITE, LK Series, type , 1600A integrally fused current limiting frame, manually operated/Draw-Out, 3P, 3PH, 200A, 800A or 1600A current sensor ratings available, 600V, 200kA@480V, originally supplied with Power Shield Type LSS solid-state trip device but can also be retrofitted with a modern Solid State electronic trip unit with LS - Long-Time and Short-Time trip functions, low voltage power air circuit breakers

SHB6G9C82, General Electric, Power Break II, type , 3P, 3PH, 600V, 4000A current sensor rating, 150kA@480V, high interrupting capacity, Bolt-On, back connected, 3000A frame rating, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, current metering & modbus communication features and 3000A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

HDL36020BHSKYP, Square D, PowerPact, type , 3P, 3PH, 20A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch low-level, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HJL36050M72AEBKSNYP, Square D, PowerPact, type , 3P, 3PH, 50A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, I - Instantaneous protection only and line & load side lug terminals, MCP, motor circuit protector, magnetic range 84-546A, Magnetic Only, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 12 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG22N0020VFFK, Eaton, Cutler Hammer, Power Defense, type , 50ºC, 1PH, 2P, 600V, 20A, 85kA@480V, Bolt-On, line side terminals only, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, IEC, CCC certifications; non-UL listed

MDN4083LEA0622NMNC4NNCMSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 600A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Castell keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

MDN4083LEA0422NMNJ2YNKMSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Kirk keylock, load side lug terminals, mechanical trip indicator & OTS switch, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

PKP36080CU63BE1BC, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 800A, 600V, 50kA@480V, UL listed, high interrupting capacity, Bolt-On, 100% rated, complete with 1A/1B alarm switch, micrologic interchangeable power 5.0P trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers

SGHH36DA6300C, General Electric, Spectra Series, type SGH, 3P, 3PH, 300A, 600V, 35kA@480V, standard interrupting capacity, 100% rated, Bolt-On, complete with SRPG600B300 rating plug, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip unit with protective relays and LIT, LIT - Long-Time, Instantaneous and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

PDF54P0800E4XM, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 800A, 100kA@480V, Bolt-On, no terminals with metric tapped conductors, complete with PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous with ARMS trip functions with relays, ZSI & CAM option, Solid State electronic, molded case circuit breakers; globally rated with 100% UL rating

KHL362001029, Square D, KHL Series, type , 3P, 3PH, 200A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, complete with 48Vdc shunt trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

SEHF36800LSIGES5E8, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 800A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 24VDC shunt trip along with 2 N.O. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PEDC4ATSE0250, General Electric, GuardEon, type , 3PH, 4P, 600V, 45-250A, 25kA@480V, front connection/Feed-Thru, toggle mechanism, complete with PremEon S interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers; meet UL, cUL, IEC, CE, CCC requirements

HJA36070AEBEYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 70A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HJA36070AEBCURYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 70A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch, 125 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

MDN4083LEA0822NMNE2ENYMWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-125Vdc UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

HGL26125BEUDYP, Square D, PowerPact, type , 2P, 1PH, 125A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 208/277 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

MPP2150KH, Murray Corporation, MPP Series, type , main circuit breaker, 2P, 1PH, 150A, 120/240V, 22kA@240V, high interrupting capacity, Plug-In, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HJXD62M400H, Siemens, Sentron Series, type , 2P, 1PH, 400A, 600V, 65kA@480V, high interrupting capacity, 50ºC, Bolt-On, 100% rated, UL listed for reverse fed applications, complete with non-interchangeable trip unit, lugs not included, Thermal Magnetic, molded case circuit breakers

SEHF363200LIES8C4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 3200A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 24VDC shunt closing coil & 24VDC shunt trip along with 2 N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them
