SSF1G3X9L, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LIGA - Long-Time, Instantaneous and Ground Fault Alarm trip functions, current metering features and 700A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

SGHH36CA4150C, General Electric, Spectra Series, type SGH, 3P, 3PH, 150A, 600V, 35kA@480V, standard interrupting capacity, 100% rated, Bolt-On, complete with SRPG400B150 rating plug, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip unit with LIT, LIT - Long-Time, Instantaneous and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

CCH3125X, Cutler Hammer, CCH Series, type , 3P, 3PH, 125A, 240V, 25kA@240V, complete with load side lug terminals, high interrupting capacity, 40°C, Bolt-On, suitable for use as main breaker, Thermal Magnetic, molded case circuit breakers

NG3900WS20, Eaton, Westinghouse, Cutler Hammer, Series C, type , 3P, 3PH, 900A, 600V, 14kA@480V, standard interrupting capacity, Bolt-On, suitable for reverse feed applications, magnetic pickup range 1250-5000, complete with left-pole mounted 480-600Vac, 50/60Hz terminal block left side mount shunt trip, I - Instantaneous trip functions, lugs not included, Solid State electronic, engine generator molded case circuit breakers

MDN4083LEA0322NMNXNNNRNWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

SGLL36CC4300C, General Electric, Spectra Series, type SGL, 3P, 3PH, 300A, 600V, 65kA@480V, high interrupting capacity, current limiting, 100% rated, Bolt-On, complete with SRPG400B300 rating plug, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip unit with LIGT, LIGT - Long-Time, Instantaneous, Ground Fault and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

SSB1G2A6B, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, back connected, 800A frame rating, complete with Entelliguard trip, LSH - Long-Time, Short-Time and High-Range Instantaneous trip functions, current metering & RELT features and 150A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

SHF3G6A2W, General Electric, Power Break II, type , 3P, 3PH, 600V, 2000A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 2000A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, current metering & RELT features and 2000A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

MDN4083LEA0822NMNKNNNCCAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 600Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Castell keylock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

MDN4083LEA0522NMNK4ENLNCX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 500A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 600Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Castell key interlock, load side lug terminals, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, unwired

MPH42W10, General Electric, M-PACT, type , frame size 2, manually operated, with cassette and 5 N.O.-3 N.C. Auxiliary switch, 4P, 3PH, 1000A, 690V, 80kA@415V, Draw-Out, NA - No Overcurrent Protection, Non-Automatic switch, insulated case circuit breakers

NDC312T52WZGP, Eaton, Cutler Hammer, Westinghouse, Series C, type , 3P, 3PH, 1200A, 600V, 100kA@480V, ultra high interrupting capacity, 40°C, Bolt-On, complete with non-interchangeable LSI - Long-Time, Short-Time and Instantaneous trip functions with zone interlocking/ground & PowerNet, lugs and rating plug not included, Digitrip OPTIM 550 Solid State Electronic molded case circuit breakers

EEFDC560100SB2, Cutler Hammer, EE Series, mounting hardware, plug-in mounting module, rated for 100A, BCL or ABR phase connection, 600V max, Copper, Single Branch mounting style, suitable for use with EHD,FDB,FD,HFD,FDC circuit breaker frames and EP panelboards; these modules are obsolete, however we still stock them

MDN4083LEA0822NMNRNENHMWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Ronis key interlock, load side lug terminals, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

THQC1290, General Electric, Q-Line, type , 1P, 1PH, 220V, 90A, 10kA@127V, UL listed, high interrupting capacity, Bolt-On, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers

SKTC3412L5W6, General Electric, Spectra Series, type , 3P, 3PH, 1200A, 480V, 65kA@480V, standard interrupting capacity, standard UL rated, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm + ZSI trip functions with extended instantaneous, advanced metering + modbus features + waveform capture features, Solid State with RELT + neutral protection, molded case circuit breakers

SHD2G5R6P, General Electric, Power Break II, type , 3P, 3PH, 600V, 1600A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 1600A frame rating, complete with Entelliguard trip, LSH - Long-Time, Short-Time and High-Range Instantaneous trip functions, full metering, modbus communication & ZSI features and 1000A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

E4S-A36-4P-3600A-DO-EO-LSI, ABB, EMax, type , 4P, 3PH, 3600A frame, 3600A rating plug, 600V, 65kA@480V, Draw-Out, electrically operated, Solid State electronic with LSI - Long-Time, Short-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

MDN4083LEA0322NMNN4YCNDWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB metal frame padlockable pushbutton cover, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 4A/4B auxiliary switch, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

E6H-A50-3P-1200A-DO-EO-LI, ABB, EMax, type , 3P, 3PH, 5000A frame, 1200A rating plug, 600V, 85kA@480V, Draw-Out, electrically operated, Solid State electronic with LI - Long-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

SHF3G6Y7P, General Electric, Power Break II, type , 3P, 3PH, 600V, 2000A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 2000A frame rating, complete with Entelliguard trip, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault trip functions, full metering, modbus communication, relays & ZSI features and 1000A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PDG53M1200E2RM, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 1200A, 65kA@480V, Bolt-On, no terminals with metric tapped conductors, complete with PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions and relays option, Solid State electronic, molded case circuit breakers; globally rated

MDN4083LEA0722NMNE4NNRNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 700A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-125Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers

E3S-A25-3P-1600A-BO-MO-LSI, ABB, EMax, type , 3P, 3PH, 2500A frame, 1600A rating plug, 600V, 65kA@480V, fixed/Bolt-On, manually operated, Solid State electronic with LSI - Long-Time, Short-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance
