26137, Merlin Gerin, Multi9, type , Z curve, magnetic setting between 2.4-3.6amp rating, 1P, 1PH, 4A, 440V, IEC rated, 6kA@415V, Feed-Thru, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic, molded case miniature circuit breakers

FM6B070TW, Siemens, Mining Service, type , 3P, 3PH, 70A, 600V, mining duty rated, 18kA@600V, standard interrupting capacity, Bolt-On, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, magnetic range 600-900A, Thermal Magnetic, Mining Service molded case circuit breakers

50HL-3-1600A-MO-DO-LSIG, Federal Pioneer, Federal Pacific, H-3 Series, 1600A frame size, manually operated/Draw-Out, 3P, 3PH, 1600A, 600V, 200kA@480V, NEMA type L fuses, multiple trip options available, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, low voltage power air circuit breakers

HNH4N800, Siemens, VL Series, type , NG Frame, 4P, 3PH, 800A, 600V, 65kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Digital Solid State Electronic molded case circuit breakers

PDG26K0100VFFN, Cutler Hammer, Eaton, Power Defense, type , 50ºC, 3PH, 4P, 60% neutral, 600V, 100A, 50kA@480V, Bolt-On, no terminals, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, IEC, CCC certifications; non-UL listed

PDG22M0070TFFJ, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 70A, 65kA@480V, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

XT2SQ4100CFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 4-Pole, 100A, 600V, 22kA@600V, Ekip DIP LIG, UL 100% Rated, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No

HFX2C250L, Siemens, VL Series, type , 2P, 1PH, 250A, 600V, 65kA@480V, high interrupting capacity, 50ºC, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, suitable for reverse fed applications, Thermal Magnetic molded case circuit breakers

MDN4083LEA0322NMNH4ENLCWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 48Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Castell key interlock, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

WLC2F312CB, Siemens, WL Series, type , frame size II, fixed mount, 3P, 3PH, 1200A, 600V, 150kA@480V, UL listed, very high interrupting capacity, Bolt-On, complete with solid state ETU727 programmer with LSI - Long-Time, Short-Time and Instantaneous trip functions and 250A rating plug, Solid State electronic, low voltage insulated case circuit breakers

PDD23P0030TFFN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 240V, 30A, 200kA@240V, Bolt-On, lugs not included, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; UL, CSA certifications

SSF1G382H, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, full metering, RELT, modbus communication, relays & ZSI features and 400A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

MPA31F0802122, General Electric, M-PACT, type , frame size 1, manually operated, with 5 N.O.-3 N.C. Auxiliary switches, 48V dc motor operator, 24/30V dc closing coil, 48V dc shunt trip and 110/130V ac undervoltage trip, 3P, 3PH, 800A, 690V, 50kA@415V, Bolt-On, NA - No Overcurrent Protection, Non-Automatic switch, insulated case circuit breakers

MDN4083LEA0522NMNCNYNRCSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 250A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

SHF2G593R, General Electric, Power Break II, type , 3P, 3PH, 600V, 1600A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 1600A frame rating, complete with Entelliguard trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, full metering, modbus communication, relays & ZSI features and 1200A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PDG22F0020VFFL, Eaton, Cutler Hammer, Power Defense, type , 50ºC, 1PH, 2P, 600V, 20A, 25kA@480V, Bolt-On, load side terminals only, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, IEC, CCC certifications; non-UL listed

MDN4083LEA0722NMNC4YNNDWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 700A current sensors and rating plugs, 600V, 42kA@600V, 40C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

MP270M, Murray Corporation, MP Series, type , 2P, 1PH, 70A, 120/240V, 10kA@240V, high interrupting capacity, marine 50°C ambient calibration, Plug-In, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers

MDN4083LEA0622NMNG4EHKNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB plastic frame padlockable pushbutton cover, 3P, 3PH, 800A, 600A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 32Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 4A/4B auxiliary switch & kirk keylock, Solid State, low voltage power insulated case circuit breakers

MDN4083LEA0722NMNJ4NNYCWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 700A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

NP631140, Federal Pacific, NP Series, type , 3P, 3PH, 1400A, 600V, 85kA@480V, standard interrupting capacity, Bolt-On, complete with interchangeable trip unit, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, insulated case circuit breakers; these breakers are obsolete; however, we do still stock them

MDN4083LEA0822NMNXNENACAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

PDG32P0250E3RJ, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 250A, 100kA@480V, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PDG54M1200D4MN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 1200A, 65kA@480V, Bolt-On, no terminals, complete with PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous with ARMS trip functions with relays and modbus option, Solid State electronic, molded case circuit breakers; globally rated
