QCHGF2025, Cutler Hammer, Quicklag, type , 2P, 1PH, 25A, 120/240V, 22kA@120V/240V, high interrupting capacity, 40°C, Feed-Thru, complete with ground fault protection, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

REE2H045L, Miami Breaker, REE Series, type , 2P, 1PH, 45A, 240V, 10kA@240V, standard interrupting capacity, Feed-Thru, complete with I - Instantaneous protection only and line & load side lug terminals, high magnetic range, MCP, motor circuit protectors, Magnetic Only, molded case circuit breakers; these breakers are obsolete, however we still stock them

1720781, Cutler Hammer, E3090V, E Series, type , 3P, 3PH, 90A, 240V, 7kA@240V, standard interrupting capacity, 50°C, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers; these breakers are now obsolete; however, we do still stock them

NMG3W600, Siemens, VL Series, type , 3P, 3PH, 600A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, interchangeable trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, lugs not included, Solid State electronic, molded case circuit breakers

LV431408X62E100, Schneider Electric, Compact NSX, type , 4P, 3PH, 250A, 690V, 36kA@415V, Bolt-On, complete with NSX250F frame and 3 pole, 100A Micrologic 6.2E trip unit with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers

SGPB36DA0150, General Electric, Spectra Series, type , 3P, 3PH, 150A, 600V, 100kA@480V, very high interrupting capacity, current limiting, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip unit with protective relays and LIT - Long-Time, Instantaneous and Targets trip functions, lugs not included, Solid State Electronic, molded molded case breakers

MDN4083LEA0822NMNENENYNWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-125Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

WLL1D312CP, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 1200A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU748 programmer+ WLGFM48 ground fault module, LSG - Long-Time, Short-Time and Ground Fault trip functions and 250A rating plug, Solid State electronic, low voltage insulated case circuit breakers

MDN4083LEA0622NMNJ2YNACSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 600A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

MDN4083LEA0422NMNGNNNHMAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 32Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Ronis key interlock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers

E3H-A20-3P-1200A-DO-EO-LI, ABB, EMax, type , 3P, 3PH, 2000A frame, 1200A rating plug, 600V, 85kA@480V, Draw-Out, electrically operated, Solid State electronic with LI - Long-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

314C637G11, Westinghouse, LA2300V, LA Series, type , 2P, 1PH, 300A, 600V, 30kA@480V, standard interrupting capacity, Bolt-On, 50°C, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

AKS-4A-50, General Electric, AK Series, type , 1600A frame, 3PH, 3P, 635VAC, 300-1600A sensor rating, 50kA@508V, Draw-Out, AKD-5, available either mechanically operated or electrically operated, with ECS, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, low voltage air circuit breakers

TFJ226100, General Electric, TFJ Series, type , 2P, 1PH, 100A, 600V, 22kA@480V, complete with load side lug terminals and non-interchangeable trip LI - Long-Time and Instantaneous trip functions, suitable for reverse feed, standard interrupting capacity, 40°C, Bolt-On, Thermal Magnetic molded case circuit breakers

MDN4083LEA0422NMNANECNCSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB metal frame padlockable pushbutton cover, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-127Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

MPA41F16N4040, General Electric, M-PACT, type , frame size 1, manually operated, with 5 N.O.-3 N.C. Auxiliary switches, Mpro-27 trip unit, 220/250V dc/ac motor operator, 220/250V dc/ac shunt trip, 4P, 3PH, 1600A, 690V, 50kA@415V, Bolt-On, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, insulated case circuit breakers

EGC3050FFGVH08, Cutler Hammer, Series G, type , 3P, 3PH, 50A, 600V, 100kA@480V, current limiting, for Marine applications 50°C, not UL listed, Feed-Thru, complete with non-interchangeable trip unit and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

SB25TP01G, Siemens, SB Series, type , Solid State digital electronic interchangeable programmer / trip unit device, complete with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, rated for 2500A, standard model including real-time voltage and current waveform displays, overcurrent protection, metering and communications, suitable for use with SBA,SBH,SBS insulated case circuit breaker frame types, these trip unit devices are now obsolete; however, we do still stock them

PDG34G0600E5WJ, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 600A, 35kA@480V, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

SHB2G4W1K, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, back connected, 1600A frame rating, complete with Entelliguard trip, LI - Long-Time and Instantaneous trip functions, full metering, RELT, modbus communication, relays & ZSI features and 600A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

SHD1G393F, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 800A frame rating, complete with Entelliguard trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, full metering, modbus communication, relays & ZSI features and 300A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

WLS2D312BQ, Siemens, WL Series, type , frame size II, drawout, 3P, 3PH, 1200A, 600V, 65kA@480V, UL listed, standard interrupting capacity, Draw-Out, complete with solid state ETU748 programmer+ WLLCD48 LCD display + WLGFM48 ground fault module, LSG - Long-Time, Short-Time and Ground Fault trip functions and 225A rating plug, Solid State electronic, low voltage insulated case circuit breakers

E4S-A32-4P-2500A-DO-MO-LI, ABB, EMax, type , 4P, 3PH, 3200A frame, 2500A rating plug, 600V, 65kA@480V, Draw-Out, manually operated, Solid State electronic with LI - Long-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

MPA32F3200150, General Electric, M-PACT, type , frame size 2, manually operated, 5 N.O- 3 N.C. Auxiliary switches, 24/30V dc closing coil and 380/400V ac shunt trip, 3P, 3PH, 3200A, 690V, 50kA@415V, fixed/Bolt-On, NA - No Overcurrent Protection, Non-Automatic switch, insulated case circuit breakers
