CFD62B100, Siemens, SENTRON, type , 2P, 1PH, 100A, 600V, 200kA@480V, current limiting, 40ºC, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic molded case circuit breakers

SEHA24AT1045C, General Electric, Spectra Series, type , 2P, 1PH, 45A, 480V, 25kA@480V, standard interrupting capacity, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable RMS trip unit with, LSI - Long-Time, Short-Time and Instantaneous trip functions, and SRPE60A45 rating plug installed, lugs not included, Solid State Electronic, molded case circuit breakers

SEPA36AT1060C, General Electric, Spectra Series, type , 3P, 3PH, 60A, 600V, 100kA@480V, very high interrupting capacity, current limiting, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable RMS trip unit with LSI - Long-Time, Short-Time and Instantaneous trip functions, and SRPE60A60 rating plug installed, lugs not included, Solid State Electronic, molded case circuit breakers

314C636G04, Westinghouse, LA2100, LA Series, type , 2P, 1PH, 100A, 600V, 30kA@480V, standard interrupting capacity, Bolt-On, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

THQD22100X2 General Electric Q-Line, Type THQD, 2P, 1PH, 100A, 240V, 22kA@240V, complete with non-interchangeable trip unit and line side lug terminals, high interrupting capacity, 40ºC, Bolt-On, thermal magnetic molded case circuit breakers

MP08-3P-200A-EO-DO-LSG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 800A frame with 250A or 400A sensor rating with 200A rating plug, 3P, 3PH, 600V, 50kA@480V, available with STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U trip units, Solid State electronic, insulated case circuit breakers

LV432108, Schneider Electric, Compact, Micrologic 6.3E trip units and programmers, type , 630A, 690V, Solid State electronic protection, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, 3 pole trip unit, suitable for use with NS,NSF,NSX,NFNF,NFNL,NFHF,NFHL frame molded case circuit breakers

WLF3S332, Siemens, WL Series, frame size III, with fuses, drawout, ANSI/UL rated, 3P, 3PH, 3200A, 600V, 200kA@480V, Draw-Out, NA - No Overcurrent Protection, low voltage Non-Automatic insulated case switch

3VA6460-7JQ31-0AA0, Siemens, SENTRON 3VA, type , 3PH, 4P, 600V, 600A, very high breaking capacity, 100kA@480V, Feed-Thru, fixed mounted, complete with ETU560 trip unit with display, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breaker

CKD3350X, Westinghouse, Cutler Hammer, Eaton, Series C, type , 3P, 3PH, 350A, 600V, 35kA@480V, standard interrupting capacity, 40ºC, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions, load side lug terminals included, 100% rated, Thermal Magnetic molded case circuit breakers

LM2800L, Westinghouse, LM Series, type , 2P, 1PH, 800A, 600V, 22kA@480V, standard interrupting capacity, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

JB31500M, Westinghouse, AB DE-ION, type , 3P, 3PH, 250A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, front adjustable, magnetic trip range 750-1500A, complete with I - Instantaneous only trip function and load side lug terminals, Magnetic Only molded case circuit breakers; these breakers are obsolete, however we do still stock them

139C4378G21 / <strong>139C4621G10 / 184L701STG19 / 139C4454G21</strong>, General Electric, General Electric, type , shunt trip, 575Vac 60Hz, suitable for use with All AK, AKR air circuit breakers

567F759G07, Eaton, Westinghouse, Cutler Hammer, DS Series, Mechanism Assembly, Complete Assembly (Without Closing Springs), for use with Manual operator, suitable for DS-632, DS-840, DSII-632, DSII-840 breakers

MP40H-3P-3000A-EO-DO-LI, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 4000A frame, includes 3000A, 3200A or 4000A sensor rating with 3000A rating plug, 3P, 3PH, 600V, 100kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

MDSC323WEA30MTCKH34YHANAX, Cutler Hammer, Eaton, Magnum DS, type , drawout mounted, 3200A standard frame, 3P, 3PH, ABC phasing, 2300A rating plug, 600V, 100kA@635V, Draw-Out, complete with interchangeable Digitrip 520M, LSI trip functions, 24Vdc shunt trip (2), 48Vdc motor operator, 48Vdc spring release, 4A/4B auxiliary, OTS/bell alarm, plastic padlock, operations counter, Thermal Magnetic, low voltage power insulated case circuit breakers

LM2125, Westinghouse, LM Series, type , 2P, 1PH, 125A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

3VL9800-1UQ00, Siemens, SENTRON 3VL, under voltage release/UVR, 227Vac, suitable for use with VL 630, 800, 1250, 1600A circuit breaker frame types

HQJ3B125H00S01, Siemens, HQJH Series, type , 3P, 3PH, 125A, 240V, 100kA@240V, very high interrupting capacity, Bolt-On, complete with 120/240V shunt trip, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete however we still stock them

504C335G05, Westinghouse, KA2125S, KA Series, type , 2P, 1PH, 125A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, Saf-T-Vue window and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

QJ23B175HA01, Siemens, QJ Frame, type , 3P, 3PH, 175A, 240V, 42kA@240V, very high interrupting capacity, Bolt-On, complete with 1A/1B auxiliary switch, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers

3VL1716-2DD36-0AA0, Siemens, SENTRON 3VL, type , 2P, 1PH, 160A, 690V, 70kA@415V, Bolt-On/fixed mount, with lug terminal, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

F3050L, Westinghouse, Cutler Hammer, F Series, type , 3P, 3PH, 50A, 600V, 14kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers; these breakers are now obsolete; however, we do still stock them

MP12-3P-600A-MO-DO-LIG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 1200A frame, includes 600A, 800A or 1200A sensor rating with 600A rating plug, 3P, 3PH, 600V, 50kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers
