PDG3XPXR30125P3M, Cutler Hammer, Eaton, Power Defense, Power Xpert Release (PXR) trip units and programmers, 3P, 600V, 125A, Solid State protection, PXR25 with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with Relays and Modbus, suitable for globally rated PDG,PDF Frame 3 circuit breakers

PDF34FH400E5RJ, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 400A, High Override, 25kA@480V, 100% UL, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

NNG3D800B, Siemens, VL Series, type , NG Frame, 3P, 3PH, 800A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, complete with LCD trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and load side lug terminals, Digital Solid State Electronic molded case circuit breakers

MP16H-3P-1600A-EO-DO-LSI, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 1600A frame, includes 1600A sensor rating and 1600A rating plug, 3P, 3PH, 600V, 65kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

LLW3B500L, Siemens, VL Series, type , 3P, 3PH, 500A, 600V, 100kA@480V, very high interrupting capacity, 40°C, Feed-Thru, 100% rated, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic molded case circuit breakers

NJY3B400 Siemens VL Series, type , 3P, 3PH, 400A, 600V, 35kA@480V, standard interrupting capacity, 40ºC, Bolt-On, 100% rated, complete with non-interchangeable trip unit, lugs not included, Thermal Magnetic molded case circuit breakers

SGLC3604L3N6 General Electric Spectra Series, type , 3P, 3PH, 400A, 600V, 65kA@480V, high interrupting capacity, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSI, LSI - Long-Time, Short-Time and Instantaneous and ZSI, zone selective interlocking, RELT, reduced energy let-through & neutral protection trip functions and advanced metering, modbus & waveform capture communication features, Solid State electronic, molded case circuit breakers

PDG33K0400D3WL, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 400A, 50kA@480V, Bolt-On, load side lug terminals, complete with PXR20D trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

JT2100TV, Cutler Hammer, Series C, type , trip units and programmers, interchangeable trip unit with LI - Long-Time and Instantaneous trip functions, rated for 100A, 50°C, suitable for HJDDC,JD,HJD,JDC molded case circuit breaker frame types, Thermal Magnetic trip units

CHKD3400V, Westinghouse, Cutler Hammer, Eaton, Series C, type , 3P, 3PH, 400A, 600V, 65kA@480V, high interrupting capacity, 50ºC, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions, 100% rated, line & load side lug terminals included, Thermal Magnetic molded case circuit breakers

LV430682D, Schneider Electric, Compact NSX, type , 4P, 3PH, 160A, 690V, 70kA@415V, Draw-Out, complete with NSX160H frame and 3 pole TM100D trip unit, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

PDG53N0800E5XM, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 800A, 85kA@480V, Bolt-On, no terminals with metric tapped conductors, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault with ARMS trip functions with relays, ZSI & CAM option, Solid State electronic, molded case circuit breakers; globally rated

371D957G73, Westinghouse, JA3700MW, JA Series, type , 3P, 3PH, 225A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, front adjustable, magnetic trip range 350-700A, complete with I - Instantaneous only trip function, lugs not included, Magnetic Only molded case circuit breakers; these breakers are obsolete, however we do still stock them

PDF34FH400E2NL, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 400A, High Override, 25kA@480V, 100% UL, Bolt-On, load side lug terminals, complete with PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions , Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

NFG3V250L, Siemens, VL Series, type , 3P, 3PH, 250A, 600V, 35kA@480V, standard interrupting capacity, Feed-Thru, interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, line & load side lug terminals, Solid State electronic, molded case circuit breakers

XT4LU4250UFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 4-Pole, 250A, 600V, 50kA@600V, Ekip Hi-Touch LSIG, UL Standard, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No - 1SDA07211R1 global reference

LA-25-250A-MO-DO, Allis Chalmers, LA Series, , 3PH, 3P, 600 VAC, 250 Frame, Manually Operated, Draw-Out, Low Voltage air circuit breaker, 15A-250 A sensor rating, Available in LS, LI, LG, LSI, LIG, LSG, or LSIG Trip Functions in multiple Trip Unit Models, For Use In Switchgear. Operating Voltage, Control Voltages, Wiring, Trip Functions, Current Sensor, Rating Plug, and Additional Accessories to be determined before ordering.

PDF54K0800P4DM, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 800A, 50kA@480V, Bolt-On, no terminals with metric tapped conductors, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip with ARMS functions with relays, modbus & CAM option, Solid State electronic, molded case circuit breakers; globally rated with 100% UL rating

PDF33GH250D2WN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 250A, High Override, 35kA@480V, 100% UL, Bolt-On, no lug terminals, complete with PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous trip functions and Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

BQ3B060M, Siemens, BQ Series, type , 3P, 3PH, 60A, 240V, 10kA@240V, standard interrupting capacity, Bolt-On, complete with Marine 50º C ambient calibration, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers

NLW3B500L, Siemens, VL Series, type , 3P, 3PH, 500A, 600V, 35kA@480V, standard interrupting capacity, 40°C, Feed-Thru, 100% rated, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic molded case circuit breakers

HLD62B450L, Siemens, Sentron Series, type , 2P, 1PH, 450A, 600V, 65kA@480V, high interrupting capacity, Feed-Thru, 40º C, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

AKR-7A-75-MO-DO-LI, General Electric, Manually Operated, Draw-out, Low Voltage air circuit breaker, AKR Series, Type , 3200A Frame, 3PH, 3P, 600Vac, {Aic Rating@480VAC}@480VAC, with MicroVersa Trip RMS-9 Solid State Overcurrent Protection, LI - Long-Time and Instantaneous trip functions, Optional Trip Functions, Current Sensor and Rating Plug Amperages available

PDG33F0250D4DN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 250A, 25kA@480V, Bolt-On, no lug terminals, complete with PXR20D trip with ARMS LSI - Long-Time, Short-Time and Instantaneous trip functions and Modbus RTU, CAM link & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications
