NPGL36100U44AYP, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 1000A, 600V, 35kA@480V, UL listed, standard interrupting capacity, Feed-Thru, complete with micrologic interchangeable ammeter 6.0A trip, fixed handle padlocking device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

HDL26050SRYP, Square D, PowerPact, type , 2P, 1PH, 50A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 125 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG23P0150D2MJ, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 150A, 100kA@480V, Feed-Thru, line & load side lug terminals, complete with Xpert Release PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, relays and modbus, Solid State electronic, molded case circuit breakers; globally rated

G2442ML3200CU, Siemens, EQ Series, type , Main Lug Only, load center, 3-phase, 3-wire, 200A rated, 24 spaces, 42 circuits, 12 max 2-poles, 240Vac, Copper bus, Type 1 indoor enclosure, to be used with EQ, Q, QJ main circuit breakers

GNH2800T33WP13, Cutler Hammer, Series G, type , 800A frame, 2P, 1PH, 600V, 65kA@480V, high interrupting capacity, Bolt-On, complete with Digitrip RMS 310 trip, LS - Long-Time and Short-Time trip functions, 600A fixed rating plug, lugs not included, Solid State electronic, molded case circuit breakers

HDA36150U31XAFBHUJ, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, alarm switch low-level, 525/600 VAC under voltage release (UVR), molded case circuit breakers

LB2350T, Westinghouse, AB DE-ION, type , interchangeable trip unit with LI - Long-Time and Instantaneous trip functions, rated for 350A, suitable for 400A- LB,HLB standard, Saf-T-Vue or MARK 75 molded case circuit breaker frame types, Thermal Magnetic trip units and programmers & circuit breakers; these trip units are obsolete, however we do still stock them

SHF1G2M9H, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LIGA - Long-Time, Instantaneous and Ground Fault Alarm trip functions, current metering, RELT, modbus communication & ZSI features and 400A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

MDN4083LEA0722NMNNNNNHNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 700A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Ronis key interlock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers

E4L-A36-3P-3200A-DO-MO-LI, ABB, EMax, type , 3P, 3PH, 3600A frame, 3200A rating plug, 600V, 125kA@480V, Draw-Out, manually operated, Solid State electronic with LI - Long-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

5925-00-839-0289, Eaton, Naval, Thermal Magnetic trip units and programmers, type -A250, 3P, 125A, 500Vac/250Vdc, 1950-3900 instantaneous trip setting, LI - Long-Time and Instantaneous trip functions, suitable for use with AQB-A250 circuit breakers for naval shipboard use

HDA36060U44XABUD, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 60A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 6.2A non-interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, complete with 2A/2B aux switch, 208/277 VAC under voltage release (UVR), molded case circuit breakers

S803S-C50, ABB, S800 Series, type , C trip curve, IEC rated, 3P, 3PH, 50A, 690V, 50kA@690V, current limiting, DIN rail mounting, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case miniature circuit breakers

SEHD36800LIF8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 800A, 600V, 150kA@480V, high interrupt rating, Draw-Out, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, complete with 2 N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDG32N0600E5ZJ, Cutler Hammer, Eaton, Power Defense, type , 1PH, 2P, 600V, 600A, 85kA@480V, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

C216LIG, General Electric, Power Break I, MicroVersaTrip Plus/PM, type , trip units and programmers, 1600A current sensor rating, Solid State electronic, LIG - Long-Time, Instantaneous and Ground Fault trip functions, suitable for use with all Power Break I TPS,TPSS,THS,THSS,TC,TCMM,THC,THCMM,THCYY,TPMM,THPVF,THPVVF,THPVV THPMM,TPR,TPRR,TPVF,TPVVF,TPYY frame insulated case circuit breakers

SEF36300ES4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 300A, 600V, 100kA@480V, Bolt-On, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 125VDC spring charging motor, shunt closing coil & shunt trip, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

MDN4083LEA0122NMNG2NHNCPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB plastic frame padlockable pushbutton cover, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 32Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 2A/2B auxiliary switch, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

MDN4083LEA0122NMNA4ENKCAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-127Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Kirk keylock, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

SEF364000LSIGES7D8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 4000A, 600V, 100kA@480V, Bolt-On, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 125VDC shunt trip along with 4A4B with 1N.O./N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

HGA36100U44XABBKUN, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 100A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 6.2A non-interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, low-level, 12 VDC under voltage release (UVR), molded case circuit breakers

PDG32K0400P4WL, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 400A, 50kA@480V, Bolt-On, load side lug terminals, complete with PXR25 trip with ARMS LSI - Long-Time, Short-Time and Instantaneous trip functions with Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PDF33GH400P8WN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 400A, High Override, 35kA@480V, 100% UL, Bolt-On, no lug terminals, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions with Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

SEHD36250LSIGES9F8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 250A, 600V, 150kA@480V, high interrupt rating, Draw-Out, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 125VDC spring charging motor, shunt closing coil & 24VDC shunt trip along with 2 N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them
