EDC3150Y, Cutler Hammer, Eaton, Westinghouse, Series C, type , 3P, 3PH, 150A, 240V, 200kA@240V, current limiting, 40ºC, Bolt-On, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line side lug terminals, Thermal Magnetic, molded case circuit breakers

FD3125VLBP10, Cutler Hammer, Eaton, Westinghouse, Series C, type , 3P, 3PH, 125A, 600V, 35kA@480V, standard interrupting capacity, 50ºC, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers, sold in bulk pack of 10, however, pricing listed is individual

SEHF361800LSES1D8, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 1800A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LS - Long-Time and Short-Time trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, shunt closing coil & shunt trip along with 4A4B with 1N.O./N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDG22G0040VFFK, Eaton, Cutler Hammer, Power Defense, type , 50ºC, 1PH, 2P, 600V, 40A, 35kA@480V, Bolt-On, line side terminals only, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, IEC, CCC certifications; non-UL listed

MP40H2-3P-2000A-MO-BO-LSI, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 4000A frame, includes 2000A, 2500A, 3000A, 3200A or 4000A sensor rating with 2000A rating plug, 3P, 3PH, 600V, 125kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

MDN4083LEA0722NMNE4NNRDPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 700A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-125Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

HGA36050BE, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 50A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, molded case circuit breakers

PJA36120CU31ABD, Square D, Schneider Electric, PowerPact, type , 3P, ABC phase connection, 3PH, 1200A, 600V, 65kA@480V, UL listed, high interrupting capacity, I-Line Style Plug-In, 100% rated, complete with 1A/1B overcurrent trip switch, micrologic interchangeable standard 3.0 trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers

S47826, Square D, Masterpact, type , rating plug, sensor plug element, rated for 6300A, suitable for use with Y-frame IEC rated 6300A - NT,NW insulated case circuit breaker frame types, for use with Micrologic solid state electronic trip units & circuit breakers

XT7LQ310DFFF000XXX, ABB, SACE Tmax XT, type , UL 100% rated, 3PH, 3P, 600V, 1000A, 100kA@480V, , front terminals, complete with Ekip trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Ekip LSI, molded case circuit breakers; 1SDA102999R1 + 1SDA107723R1 global reference

REH3A010, Miami Breaker, REH Series, type , 3P, 3PH, 10A, 480V, 14kA@480V, standard interrupting capacity, Bolt-On, complete with I - Instantaneous protection only and load side lug terminals, standard magnetic range, MCP, motor circuit protectors, Magnetic Only, molded case circuit breakers; these breakers are obsolete, however we still stock them

HDL26100ABUH, Square D, PowerPact, type , 2P, 1PH, 100A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, 380/480 VAC under voltage release (UVR), molded case circuit breakers

HJA36020BKUJYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 20A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, low-level, 525/600 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

MDN4083LEA0122HLC32ENNNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, factory installed 48Vdc shunt trip (ST), 24Vdc second shunt trip (STA) & 2A/2B auxiliary switch, electrically operated with factory installed 24Vdc motor operator & spring release device (SRD), Solid State, low voltage power insulated case circuit breakers

CJD62L400L, Siemens, SENTRON, type , 2P, 1PH, 400A, 600V, 150kA@480V, fuseless current limiting, Feed-Thru, complete with I - Instantaneous protection only, low instantaneous range, line & load side lug terminals, MCP, motor circuit protectors, magnetic range 1250-2500A, Magnetic Only, molded case circuit breakers

PDF64N2000P2DN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 2000A, 85kA@480V, Bolt-On, no terminals, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions with relays, modbus & CAM option, Solid State electronic, molded case circuit breakers; globally rated with 100% UL rating

MDN4083LEA0422NMNR4YCNCCX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB metal frame padlockable pushbutton cover, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 4A/4B auxiliary switch, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, unwired

WLL2D312EH, Siemens, WL Series, type , frame size II, drawout, 3P, 3PH, 1200A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU745 programmer + WLLCD48 LCD display + WLGFM48 ground fault module, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and 315A rating plug, Solid State electronic, low voltage insulated case circuit breakers

MPA41F12N3320, General Electric, M-PACT, type , frame size 1, manually operated, with 5 N.O.-3 N.C. Auxiliary switches, Mpro-27 trip unit, 110/130V dc/ac motor operator, 110/130V dc/ac closing coil and 48V dc shunt trip, 4P, 3PH, 1250A, 690V, 50kA@415V, Bolt-On, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, insulated case circuit breakers

FGN26AA0250R2, General Electric, Record Plus, type , FG600 frame, 2P, 1PH, 250A, 600V, 65kA@480V, standard interrupting capacity, Bolt-On, complete with SMR1 electronic trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Solid State electronic molded case circuit breakers

MDN4083LEA0222NMNC4ENNNCX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 200A current sensors and rating plugs, 600V, 42kA@600V, 40C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions & load side lug terminals, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, unwired

MDN4083LEA0422NMNJNYNCMWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Castell keylock, load side lug terminals, mechanical trip indicator & OTS switch, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

MDN4083LEA0222NMNR4YNLCWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 200A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Castell key interlock, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

953 209, DEHN part and accessory
