QO2451021, Square D, QO Series, type , 2P, 1PH, 45A, 120/240V, 10kA@240V, Plug-In, UL listed as HACR type, common trip, complete with VISI-TRIP indicator, 120V shunt trip, Thermal Magnetic molded case miniature circuit breakers suitable for QO Series load centers

SHB6G9X11, General Electric, Power Break II, type , 3P, 3PH, 600V, 4000A current sensor rating, 150kA@480V, high interrupting capacity, Bolt-On, back connected, 3000A frame rating, complete with Entelliguard trip, LI - Long-Time and Instantaneous trip functions, current metering features and 2500A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

HDA260304AESKYP, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 30A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

EE3A045L, ITE, Siemens, EE Series, type , 3P, 3PH, 45A, 240V, 10kA@240V, standard interrupting capacity, Feed-Thru, complete with I - Instantaneous protection only and line & load side lug terminals, standard magnetic range, MCP, motor circuit protectors, Magnetic Only, molded case circuit breakers

BAB2070S1, Cutler Hammer, Eaton, Westinghouse, Quicklag, type , 2P, 1PH, 70A, 120/240V, 10kA@240V, standard interrupting capacity, 40°C, Bolt-On, complete with 12/48V shunt trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers

MDN4083LEA0122RPRGNENNNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, factory installed 208-250Vdc shunt trip (ST) & 32Vdc UVR, electrically operated with factory installed 220-240Vac motor operator & 208-250Vac spring release device (SRD), Solid State, low voltage power insulated case circuit breakers

TEY3070 General Electric Q-Line, Type TEY, 3P, 3PH, 70A, 277/480V, 14kA@480V, complete with load side lug terminals, standard interrupting capacity, 40ºC, Bolt-On, Thermal Magnetic molded case circuit breakers

HDL36020AABESKYP, Square D, PowerPact, type , 3P, 3PH, 20A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HJL36150M74AASKYP, Square D, PowerPact, type , 3P, 3PH, 150A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, I - Instantaneous protection only and line & load side lug terminals, MCP, motor circuit protector, magnetic range 348-1690A, Magnetic Only, complete with 1A/1B aux switch, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

MPA120AFHH, Murray Corporation, MP Series, type , 1P, 1PH, 20A, 120V, 65kA@120V, very high interrupting capacity, 40°C, Plug-In, complete with arc fault, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers

SEHF361600LSIGES6A8, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 1600A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 48VDC shunt trip along with 4A4B with 1N.O./N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

SSF1G3K4H, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions, current metering & ZSI features and 400A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

LNY4N800, Siemens, VL Series, type , NG Frame, 4P, 3PH, 800A, 600V, 100kA@480V, very high interrupting capacity, current limiting, Bolt-On, 100% rated, suitable for reverse feed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Digital Solid State Electronic molded case circuit breakers

HGA260904AFBCSH, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 90A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch, 380/480 VAC shunt trip, molded case circuit breakers

MDN4083LEA0822NMNCNNNRCPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

HJA36020AEBHUK, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 20A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch low-level, 24 VAC under voltage release (UVR), molded case circuit breakers

SED361800LIGES9B4, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 1800A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LIG - Long-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 125VDC spring charging motor, shunt closing coil & 24VDC shunt trip along with 2 N.O. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDF33F0250P2MK, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 250A, 25kA@480V, 100% UL, Bolt-On, line side lug terminals, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions and Modbus RTU & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

SEHD361000LSIGF8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 1000A, 600V, 150kA@480V, high interrupt rating, Draw-Out, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, complete with 2 N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

EEHMDL360600TB2, Cutler Hammer, EE Series, mounting hardware, plug-in mounting module, rated for 600A, ABC phase connection, 600V max, Copper, Dual/Twin Branch mounting style, suitable for use with MDL,HMDL circuit breaker frames and EP panelboards; these modules are obsolete, however we still stock them

<strong>EHD1100BP10</strong>, Cutler Hammer / Eaton / Westinghouse, Series C, type EHD, 1P, 1PH, 100A, 277V, 14kA@480V, standard interrupting capacity, 40ºC, bolt-on, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, thermal magnetic, molded case circuit breakers, sold in bulk pack of 10, however, pricing listed is individual

MDN4083LEA0522NMNCNYNNMAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 250A current sensors and rating plugs, 600V, 42kA@600V, 40&deg;C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

K600S-MO-DO-LIG, ABB, K-Line, type , 600A frame size, manually operated/Draw-Out, 3P, 3PH, 600A, 600V, 30kA@480V, originally supplied with SS solid state trip device but can also be retrofitted with a modern Solid State electronic trip unit with LIG - Long-Time, Instantaneous and Ground Fault trip functions, low voltage power air circuit breakers

PKD36040U73AE1BC, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 400A, 600V, 50kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with 1A/1B alarm switch, micrologic interchangeable harmonic 5.0H trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers
