MDN4083LEA0422NMNC4NNNDAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

GRC316T35WP07, Cutler Hammer, Series G, type , 1600A frame, 3P, 3PH, 600V, 100kA@480V, very high interrupting capacity, Bolt-On, complete with Digitrip RMS 310 trip, LSG - Long-Time, Short-Time and Ground Fault trip functions, 800A fixed rating plug, Solid State electronic, molded case circuit breakers

MN4R1M10-A, General Electric, M-PACT Plus, type , frame size 1, manually operated, without cassette, moving portion only, 5 N.O.-3 N.C. Auxiliary switch, 4P, 3PH, right side neutral, 1000A, 690V, 65kA@415V, Draw-Out, to be used with MPRO-27 or MPRO-50 programmer with optional long-time, short-time and instantaneous (LSI) or LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, insulated case circuit breakers

SHF1G1X8B, General Electric, Power Break II, type , 3P, 3PH, 600V, 200A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, current metering features and 150A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

MDN4083LEA0122NMNN4ECNMCX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB metal frame padlockable pushbutton cover, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 4A/4B auxiliary switch, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, unwired

MDN4083LEA0422NMNR4YNKDPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Kirk keylock, load side lug terminals, mechanical trip indicator, OTS switch & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

MDN4083LEA0122NMNF2NNRDAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 220-250Vdc UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

WLL2D325LW, Siemens, WL Series, type , frame size II, drawout, 3P, 3PH, 2500A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU755 programmer + WLGFA76 ground fault module, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions and 630A rating plug, Solid State electronic, low voltage insulated case circuit breakers

SSF2G422K, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, front connected, 1600A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, current metering, RELT, modbus communication & ZSI features and 600A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

SHF1G3J2L, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, full metering, modbus communication and relays features and 700A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

LFG3C125B Siemens VL Series, type , 3P, 3PH, 125A, 600V, 100kA@480V, very high interrupting capacity, 50℃, Bolt-On, complete with load side lug terminals, Thermal Magnetic molded case circuit breakers

PDG24G0100D3MK, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 100A, 35kA@480V, Bolt-On, line side lug terminals, complete with Xpert Release PXR20D trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, relays and modbus, Solid State electronic, molded case circuit breakers; globally rated

SHD1G2X3D, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 800A frame rating, complete with Entelliguard trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, current metering features and 225A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

MDN4083LEA0222NMNX2NNCMCX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 200A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Castell keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, unwired

MDN4083LEA0322NMNX4YNYMWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals, mechanical trip indicator & OTS switch, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

EELCL420200SB2, Cutler Hammer, EE Series, mounting hardware, plug-in mounting module, rated for 200A, ABL or BCR phase connection, 240V max, Copper, Single Branch mounting style, suitable for use with LCL circuit breaker frames and EP panelboards; these modules are obsolete, however we still stock them

SELA36AG0150, General Electric, Spectra Series, type , 3P, 3PH, 150A, 600V, 65kA@480V, high interrupting capacity, current limiting, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable RMS trip unit with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

PDG63N2000E2ZN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 2000A, 85kA@480V, Bolt-On, no terminals, complete with PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions with modbus & ZSI option, Solid State electronic, molded case circuit breakers; globally rated

PDF34F0250P8WJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 250A, 25kA@480V, 100% UL, Feed-Thru, line & load side lug terminals, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions with Modbus RTU, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

S203-B13, ABB, S 200 Series, type , 3P, 3PH, 13A, 480V, 6kA@480V, standard interrupting capacity, current limiting, DIN rail mounted, Feed-Thru, suitable for reverse feed, UL/CSA/IEC approval, branch circuit protection, B trip characteristic, Thermal Magnetic trip functions, Thermal Magnetic, miniature molded case circuit breakers and supplemental protectors

BR2100SR12, Westinghouse, Cutler Hammer, BR Series, type , 2P, 1PH, 100A, 120/240V, 10kA@240V, standard interrupting capacity, 40ºC, Plug-In, with 12V shunt trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers

MDN4083LEA0522NMNF2YNYNWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 250A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 220-250Vdc UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals, mechanical trip indicator & OTS switch, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

6635C58G12, Eaton, Naval, type -A1602, rating plug, 400A, suitable for use with 800A AQB-A1602,NQB-A1602 naval circuit breakers

SHD4G6N7N, General Electric, Power Break II, type , 3P, 3PH, 600V, 2000A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 2500A frame rating, complete with Entelliguard trip, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault trip functions, current metering, modbus communcation & ZSI features and 800A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems
