SHD25B210H, General Electric, Power Break II, type , 3P, 3PH, 600V, 2500A frame, with 1000A rated trip, 150kA@480V, high interrupting capacity, Draw-Out, complete with MicroVersaTrip Plus programmer trip device, high-range instantaneous protection, Solid State, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

HFX3C250, Siemens, VL Series, type , 3P, 3PH, 250A, 600V, 65kA@480V , high interrupting capacity, 50ºC, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, suitable for reverse fed applications, Thermal Magnetic molded case circuit breakers

WLL2D330QT, Siemens, WL Series, type , frame size II, drawout, 3P, 3PH, 3000A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU755 programmer + WLGFA76 ground fault module, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions and 1200A rating plug, Solid State electronic, low voltage insulated case circuit breakers

SSD4G6N8R, General Electric, Power Break II, type , 3P, 3PH, 600V, 2000A current sensor rating, 65kA@480V, standard interrupting capacity, Draw-Out, 2500A frame rating, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, current metering, modbus communcation & ZSI features and 1200A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

SHD4G6L4U, General Electric, Power Break II, type , 3P, 3PH, 600V, 2000A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 2500A frame rating, complete with Entelliguard trip, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions, current metering, RELT & ZSI features and 1600A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

CH32H150R, Cutler Hammer, CH Series, Main Breaker load center, outdoor NEMA 3R enclosure, 1-phase, 3-wire, 120/240V, 150A with CHH main breaker rated 100kAIC, 32 spaces

MPA31F20N4100, General Electric, M-PACT, type , frame size 1, manually operated, with 5 N.O.-3 N.C. Auxiliary switches, Mpro-27 trip unit, 220/250V dc/ac motor operator and 24/30V dc closing coil, 3P, 3PH, 2000A, 690V, 50kA@415V, Bolt-On, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, insulated case circuit breakers

SKSS3410L5X8, General Electric, Spectra Series, type , 3P, 3PH, 1000A, 480V, 100kA@480V, standard interrupting capacity, 100% rated, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions and extended instantaneous, advanced metering +modbus + waveform capture + relays features, Solid State electronic, molded case circuit breakers

KXTCAXDS51W, ABB, SACE Tmax XT, cabled auxiliary contact, AUX-S51-C 24 V DC, suitable for use with withdrawable XT2,XT3,XT4 molded case circuit breakers; 1SDA067117R1 global reference

SSF5G8Z2W, General Electric, Power Break II, type , 3P, 3PH, 600V, 3000A current sensor rating, 100kA@480V, standard interrupting capacity, Bolt-On, front connected, 3000A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, current metering & ZSI features and 2000A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

HE2L005L, ITE, Siemens, HE Series, type , 2P, 1PH, 5A, 480V, 25kA@480V, high interrupting capacity, Feed-Thru, complete with I - Instantaneous protection only and line & load side lug terminals, low magnetic range, MCP, motor circuit protectors, Magnetic Only, molded case circuit breakers

PDF44G0800P3WK, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 800A, 35kA@480V, Bolt-On, line side lug terminals, complete with PXR25 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, relays, modbus and ZSI, Solid State electronic, molded case circuit breakers; globally rated, 100% UL rated

568B604G6, General Electric, SST Solid State Programmer, 300-4000A, Long Time, Short Time (HI) 3L to 10L Range, Instantaneous, suitable for use with AK, AKR air circuit breakers

EHB1060S, Westinghouse, Cutler Hammer, AB DE-ION, type , 1P, 1PH, 60A, 277V, 10kA@277V, standard interrupting capacity, 40°C, Bolt-On, with 'safety view' window, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers; these breakers are now obsolete; however, we do still stock them

XT7SQ380CCFF000XXX, ABB, SACE Tmax XT, type , UL 100% rated, 3PH, 3P, 600V, 800A, 50kA@480V, Bolt-On, front terminals, complete with Ekip trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, Ekip DIP LIG, molded case circuit breakers; 1SDA102944R1 + 1SDA107723R1 global reference

SHB2G4B3H, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, back connected, 1600A frame rating, complete with Entelliguard trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, current metering, RELT & modbus communication features and 400A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PDG34N0125E5RL, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 125A, 100kA@480V, Bolt-On, load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

MDN4083LEA0422NMNX2NNRDSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

PDG24K0100D2DJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 100A, 50kA@480V, Feed-Thru, line & load side lug terminals, complete with Xpert Release PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, relays, modbus and CAM, Solid State electronic, molded case circuit breakers; globally rated

PBF3600V, Westinghouse, PBF Series, type , 3P, 3PH, 600A, 600V, 100kA@480V, 50° C, Bolt-On, front connected, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

MDN4083LEA0422NMNJNNNKMPX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Kirk keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, pre-wired

PDG32M0125D2MN, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 125A, 65kA@480V, Bolt-On, no lug terminals, complete with PXR20D trip with LSI - Long-Time, Short-Time and Instantaneous trip functions and Modbus RTU & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

MDN4083LEA0322NMNXNNNHDSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Ronis key interlock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

TA9VT32GA3, General Electric, MicroVersaTrip, type , Solid State trip units and programmers, 3200A, LIGT - Long-Time, Instantaneous, Ground Fault and Targets trip functions, suitable to be used with 3000/3200A AK,AKR,POWERBREAK,MICROVERSATRIP molded case, insulated case and low voltage power air circuit breakers
