MP08H-3P-600A-EO-BO-LSI, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 800A frame, includes 600A or 800A sensor rating with 600A rating plug, 3P, 3PH, 600V, 65kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP trip units, Solid State electronic, insulated case circuit breakers

SGLL36CA4225C, General Electric, Spectra Series, type SGL, 3P, 3PH, 225A, 600V, 65kA@480V, high interrupting capacity, current limiting, 100% rated, Bolt-On, complete with SRPG400B225 rating plug, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip unit with LIT, LIT - Long-Time, Instantaneous and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

MP12-3P-800A-MO-DO-LSIG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 1200A frame with 800A or 1200A sensor rating with 800A rating plug, 3P, 3PH, 600V, 50kA@480V, accepts the following programmers/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

PKO50D4F1608, General Electric, trip units and programmers, ProTrip Solid State conversion kits, 3P, 4-wire, 1600A sensor rating, 600V, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, replaces an electromechanical trip unit in 1600A frame AK-50,AKU-50,AKT-50,AKS-50,AKSU-50,AKST-50 low voltage power air circuit breakers

HMCP400F5S13, Cutler Hammer, Eaton, Westinghouse, Series C, type , K Frame, 3P, 3PH, 400A, 600V, 35kA@480V, Feed-Thru, complete with left-pole mounted 380-440Vac or 220-250Vdc left side shunt trip, I - Instantaneous Protection Only and standard line & load side lug terminals, magnetic range 625-1250A, Magnetic Only, molded case circuit breakers

HDA36060U31XABBCSVYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 60A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B aux switch, alarm switch, 60 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HGA260702AESJYP, Square D, PowerPact, type , 1PH, 2P, A & C phase connection, 70A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, 525/600 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

SKHH36DD2600C, General Electric, Spectra Series, type , 3P, 3PH, 600A, 600V, 50kA@480V, complete with SRPK1200B600 rating plug, standard interrupting capacity, 100% rated, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip with protective relays and LSIGT - Long-Time, Short-Time, Instantaneous, Ground Fault and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

HJL36045BE, Square D, PowerPact, type , 3P, 3PH, 45A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, molded case circuit breakers

XT4NQ3250EFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 3-Pole, 250A, 600V, 18kA@600V, Ekip LS/I (Electronic, LS/I protection), UL 100% Rated, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No - 1SDA07211R1 global reference

LGN46600U53X, Square D, Schneider Electric, PowerPact, type , 4P, 3PH, 600A, 600V, 35kA@480V, UL listed, high interrupting capacity, Plug-In, complete with non-interchangeable micrologic energy 5.3E trip unit, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers

HDA260401AFBEUO, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 40A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, 24 VDC under voltage release (UVR), molded case circuit breakers

HDA36020AFBKSJYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 20A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 525/600 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDS26030, Schneider Electric, Square D, PowerPact, type , 2P, 1PH, 30A, 600V, 18kA@480V, standard interrupting capacity, Bolt-On, rear connected, UL listed, suitable for reverse feed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HDA260302ABSLYP, Square D, PowerPact, type , 1PH, 2P, A & C phase connection, 30A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PKF36040CU73BE1, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 400A, 600V, 50kA@480V, UL listed, high interrupting capacity, Bolt-On, 100% rated, complete with micrologic interchangeable harmonic 5.0H trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs not included, Solid State electronic, molded case circuit breakers

HMX2B700, Siemens, VL Series, Type , 2P, 1PH, 700A, 600V, 65kA@480V, high interrupting capacity, 40°C, Bolt-On, complete with non-interchangeable trip unit, lugs not included, suitable for reverse fed applications, Thermal Magnetic molded case circuit breakers

HGA260901ABSHYP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 90A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, 380/480 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

NDG2B100B, Siemens, VL Series, type , 2P, 1PH, 100A, 600V, 35kA@480V, standard interrupting capacity, 40ºC, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers

HDA36090SH, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 90A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, complete with 380/480Vac shunt trip, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

E3RED42B035, Siemens, SENTRON, type , 2P, 1PH, 35A, 480V, 18kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, complete with Type 3R enclosure, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

HDA260401AEBCSP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 40A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch, 48 VDC shunt trip, molded case circuit breakers

HDA36125AFBCSLYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 125A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

THED134020WL, General Electric, E150 Line, type , 3P, 3PH, 20A, 480V, 25kA@480V, complete with line & load side lug terminals, high interrupting capacity, 40°C, Feed-Thru, Thermal Magnetic, molded case circuit breakers
