HDA260404AEBESR, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 40A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, 125 VDC shunt trip, molded case circuit breakers

ED3175LS01, Cutler Hammer, Eaton, Westinghouse, Series C, type , 3P, 3PH, 175A, 240V, 65kA@240V, standard interrupting capacity, 40ºC, Feed-Thru, includes left pole mounted 12-24Vac shunt trip, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

XT4VQ3060FFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 3-Pole, 60A, 600V, 65kA@600V, Ekip LSI (Electronic, LSI protection), UL 100% Rated, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No - 1SDA07211R1 global reference

HMCP070J2S14, Eaton, Westinghouse, Cutler Hammer, Series C, type , F Frame, 3P, 3PH, 70A, 600V, 65kA@480V, Feed-Thru, complete with left-pole mounted 415-600Vac or 220-250Vdc rear shunt trip, non-interchangeable trip with I - Instantaneous Protection Only, standard line & load side lug terminals, MCP, motor circuit protector, magnetic range 115-170A, Magnetic Only, molded case circuit breakers

XT4HU4225EFF000XXX, ABB, molded case circuit breaker, SACE Tmax XT, Type , 4-Pole, 225A, 600V, 25kA@600V, Ekip LS/I (Electronic, LS/I protection), UL Standard, Line Side Termination (top): F front terminals no lugs installed, Load Side Termination (bottom): F front terminals no lugs installed, No - 1SDA07211R1 global reference

HDA260251ABBEUO, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 25A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, 24 VDC under voltage release (UVR), molded case circuit breakers

Q1190VH, Square D, Q1 Series, type , 1P, 1PH, 90A, 120V, 22kA@120V, very high interrupting capacity, 40°C, Plug-In, Thermal Magnetic, molded case circuit breakers; these breakers are now obsolete; however, we do stock them

PDD23G0225TFFK, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 240V, 225A, 65kA@240V, Bolt-On, line terminals only, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; UL, CSA certifications

S3HQ025TW, ABB, SACE Isomax, type , 3P, 3PH, 25A, 600V/500VDC, 50kA@480V, 65kA@415V, 100% UL rated, Bolt-On, suitable for reverse feed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HGA260901AFBHSNYP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 90A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch low-level, 12 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDA36035AEBCSR, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 35A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch, 125 VDC shunt trip, molded case circuit breakers

SGPC3604L5NX General Electric Spectra Series, type , 3P, 3PH, 400A, 600V, 100kA@480V, extra high interrupting capacity, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIA, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm and ZSI, zone selective interlocking, RELT, reduced energy let-through & neutral protection trip functions and basic metering communication features, Solid State electronic, molded case circuit breakers

HGA36150U33XAFUR, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2S non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, 125 VDC under voltage release (UVR), molded case circuit breakers

HGA260904BCUAYP, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 90A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch, 120 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

FGH36AA0250R3, General Electric, Record Plus, type , FG600 frame, 3P, 3PH, 250A, 600V, 100kA@480V, high interrupting capacity, Bolt-On, complete with SMR1 electronic trip, LI - Long-Time and Instantaneous trip functions and line side lug terminals, Solid State electronic molded case circuit breakers

HGA36035BESKYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 35A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDA260901AABHUSYP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 90A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch low-level, 250 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

KC242251027, Square D, I-Line, Type , 2P, 1PH, 225A, 480V, 65kA@480V, extra high interrupting capacity, 40°C, I-Line Style Plug-In, complete with 24Vdc shunt trip, Thermal Magnetic molded case circuit breakers

LV430403X62A100 Schneider Electric Compact NSX, type , 3P, 3PH, 160A, 690V, 36kA@415V, Bolt-On, complete with NSX160F frame and 3 pole, 100A Micrologic 6.2A trip unit with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers

JXD22B250L, Siemens, Sentron Series, type , 2P, 1PH, 250A, 240V, 65kA@240V, standard interrupting capacity, 40ºC, Feed-Thru, complete with non-interchangeable trip unit and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

HDA36060U31XAABCUKYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 60A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 1A/1B aux switch, alarm switch, 24 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDD22K0050VFFK, Cutler Hammer, Eaton, Power Defense, type , 50ºC, 1PH, 2P, 240V, 50A, 85kA@240V, Bolt-On, line terminals only, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; IEC certification; non-UL listed

PDG34PH250D3YN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 250A, High Override, 100kA@480V, Bolt-On, no lug terminals, complete with PXR20D trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and Modbus RTU, CAM Link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

EGEDC3045FFG, Eaton, Cutler Hammer, Series G, type , 3P, 3PH, 45A, 600V, DC rated, 35kA@500V, high interrupting capacity, 40°C, Feed-Thru, complete with non-interchangeable trip unit and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers
