HRA36100U31XABBKSR, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 100A, 600V, 200kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, low-level, 125 VDC shunt trip, molded case circuit breakers

HDL26050ABBCUS, Square D, PowerPact, type , 2P, 1PH, 50A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch, 250 VDC under voltage release (UVR), molded case circuit breakers

HGA36060AFBHSK, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 60A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch low-level, 24 VAC shunt trip, molded case circuit breakers

CC3100HM, Cutler Hammer, CC Series, type , 3P, 3PH, 100A, 240V, 10kA@240V, hi magnetic range, complete with line & load lug terminals, standard interrupting capacity, 40°C, Feed-Thru, suitable for use as main breaker, Thermal Magnetic, molded case circuit breakers

AE-1-25-400A-MO-DO, General Electric, AE Series, , 3PH, 3P, 600 VAC, 400 Frame, Manually Operated, Draw-Out, Low Voltage air circuit breaker, 15A-400 A sensor rating, Available in LS, LI, LG, LSI, LIG, LSG, or LSIG Trip Functions in multiple Trip Unit Models, For Use In Switchgear. Operating Voltage, Control Voltages, Wiring, Trip Functions, Current Sensor, Rating Plug, and Additional Accessories to be determined before ordering.

LMG3B600, Siemens, VL Series, type , 3P, 3PH, 600A, 600V, 100kA@480V, very high interrupting capacity, 40ºC, Bolt-On, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic molded case circuit breakers

HLCCG3350, Westinghouse, SELTRONIC, type , 3P, 3PH, 350A, 600V, 35kA@480V, high interrupting capacity, Bolt-On, 100% rated, complete with rating plug, Solid State electronic molded case circuit breakers; these breakers are obsolete, however we do still stock them

76R122, Square D, Micrologic, torroidal Current Transformers, 600V class, 2-11/32 window size, 1200:5, suitable for Micrologic circuit breakers

HDA36030AEBKUR, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 30A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 125 VDC under voltage release (UVR), molded case circuit breakers

SKLC3612L4LX General Electric Spectra Series, type , 3P, 3PH, 1200A, 600V, 65kA@480V, high interrupting capacity, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIG, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault and ZSI, zone selective interlocking & RELT, reduced energy let-through trip functions and basic metering communication features, Solid State electronic, molded case circuit breakers

HDL26100AABKUSYP, Square D, PowerPact, type , 2P, 1PH, 100A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, low-level, 250 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDA36150AABHUDYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch low-level, 208/277 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDA260304AFBCSR, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 30A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch, 125 VDC shunt trip, molded case circuit breakers

HJA36030AABHUA, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 30A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch low-level, 120 VAC under voltage release (UVR), molded case circuit breakers

HJA36150AAUP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 150A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, 48 VDC under voltage release (UVR), molded case circuit breakers

EE1H030L, Siemens, ITE, EE Series, type , 1P, 1PH, 30A, 120V, 10kA@120V, standard interrupting capacity, Feed-Thru, complete with I - Instantaneous protection only and line & load side lug terminals, high magnetic range, MCP, motor circuit protectors, Magnetic Only, molded case circuit breakers

PDG34P0600E3CK, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 600A, 100kA@480V, Bolt-On, line side lug terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and CAM link & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PDG33P0400E5RJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 400A, 100kA@480V, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PDG4XPXR40800E2W, Eaton, Cutler Hammer, Power Defense, Power Xpert Release (PXR) trip units and programmers, 4P, 600V, 800A, Solid State protection, PXR20 with LSI - Long-Time, Short-Time and Instantaneous trip functions with relays, modbus and ZSI options, suitable for globally rated PDG,PDG Frame 4 circuit breakers

HRA36100U31XAFBEUD, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 100A, 600V, 200kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, 208/277 VAC under voltage release (UVR), molded case circuit breakers

HGL36090AEBESHYP, Square D, PowerPact, type , 3P, 3PH, 90A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, 380/480 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

LAF-600-600A-MO-DO, Allis Chalmers, LAF Series, , 3PH, 3P, 600 VAC, 600 Frame, Manually Operated, Draw-Out, Low Voltage air circuit breaker, 15A-600 A sensor rating, Available in LS, LI, LG, LSI, LIG, LSG, or LSIG Trip Functions in multiple Trip Unit Models, For Use In Switchgear. Operating Voltage, Control Voltages, Wiring, Trip Functions, Current Sensor, Rating Plug, and Additional Accessories to be determined before ordering.

HGA260901AABCUK, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 90A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch, 24 VAC under voltage release (UVR), molded case circuit breakers

DB-25-600A-MO-BO, Westinghouse, DB Series, , 3PH, 3P, 600 VAC, 600 Frame, Manually Operated, Bolt-On, Low Voltage air circuit breaker, 15A-600 A sensor rating, Available in LS, LI, LG, LSI, LIG, LSG, or LSIG Trip Functions in multiple Trip Unit Models For Use In De-ion DB Switchgear. Operating Voltage, Control Voltages, Wiring, Trip Functions, Current Sensor, Rating Plug, and Additional Accessories to be determined before ordering.
