FA42WN32B, General Electric, M-PACT Plus, circuit breaker accessory, Connection Devices, bottom front access connectors for frame size 2, withdrawable/draw-out connection, 4 pole, 800-3200A, type MN air circuit breakers

MDN4083LEA0322NMNNNNNNNSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

RL-3200A-MO-BO-LS, Siemens-Allis, RL Series, type , 3200A frame size, manually operated/stationary mounted, 3P, 3PH, 1200-3200A current sensor rating, 600V, 85kA@480V, originally supplied with StaticTrip III RMS trip device but can also be retrofitted with a modern Solid State electronic trip unit with LS - Long-Time and Short-Time trip functions, low voltage power air circuit breakers

NZMN1-S18-CNA, Eaton, Klockner Moeller, NZM1 Series, type , 3P, 3PH, 600V, 18A, 35kA@480V, normal switching capacity, Bolt-On/fixed mounting, with screw terminals, Thermal Magnetic, molded case circuit breakers, UL/CSA rated

PDG32PH250P4MN, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 250A, High Override, 100kA@480V, Bolt-On, no lug terminals, complete with PXR25 trip with ARMS LSI - Long-Time, Short-Time and Instantaneous trip functions and Modbus RTU & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

SSF30Y330, General Electric, Power Break II, type , 3P, 3PH, 3000A, 600V, 100kA@480V, standard interrupting capacity, Bolt-On, front connected, Non-Automatic insulated case switch, NA - No Overcurrent Protection, suitable for use with Power Break II switchgear systems

PDG34N0125E3XJ, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 125A, 100kA@480V, Feed-Thru, line & load side lug terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with CAM link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

SGPP36CD6500C, General Electric, Spectra Series, type , 3P, 3PH, 500A, 600V, 100kA@480V, complete with SRPG600B500 rating plug, very high interrupting capacity, current limiting, 100% rated, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, PM trip unit with LSIGT, LSIGT - Long-Time, Short-Time, Instantaneous, Ground Fault and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers

WLL1D316PE, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 1600A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU745 programmer + WLGFA48, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions and 1000A rating plug, Solid State electronic, low voltage insulated case circuit breakers

SHD4G4N2N, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 2500A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, current metering, modbus communication & ZSI features and 800A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PDG62N2000P4DM, Eaton, Cutler Hammer, Power Defense, type , 1PH, 2P, 600V, 2000A, 85kA@480V, Bolt-On, no terminals with metric tapped conductors, complete with PXR25 trip with LSI - Long-Time, Short-Time and Instantaneous trip with ARMS functions with relays, modbus & CAM option, Solid State electronic, molded case circuit breakers; globally rated

SHF1G1L8C, General Electric, Power Break II, type , 3P, 3PH, 600V, 200A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, current metering, RELT & ZSI features and 200A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PDD22F0035TFFJ, Cutler Hammer, Eaton, Power Defense, type , 1PH, 2P, 240V, 35A, 35kA@240V, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; CSA, UL, certifications

SPB100-3P-400A-MO-DO-LSI, Cutler Hammer, Systems Pow-R, type , 800A frame size, 3P, 3PH, 400A, 600V, 100kA@480V, standard interrupting capacity, Draw-Out, manually operated, available with Pow-R Trip, Pow-R Trip 7, Digitrip RMS 510, 610, 810, 910, Digitrip OPTIM 750 and 1050, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, insulated case circuit breakers; these breakers are obsolete, however we still stock them

KDON-1600S-EO-BO-LSI, ABB, K-Line, type , 1600A fused frame size, electrically operated/Bolt-On, 3P, 3PH, 1600A, 600V, 200kA@480V, originally supplied with SS solid state trip device but can also be retrofitted with a modern Solid State electronic trip unit with LSI - Long-Time, Short-Time and Instantaneous trip functions, low voltage power air circuit breakers

MDN4083LEA0622NMNR4NNRDAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 600A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

SHB1G2A8D, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, back connected, 800A frame rating, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, current metering & RELT features and 225A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PDG23F0225E3WN, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 225A, 25kA@480V, Bolt-On, no lug terminals, complete with Xpert Release PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, relays, modbus and ZSI, Solid State electronic, molded case circuit breakers; globally rated

THC4040TTE3, General Electric, Power Break I, type , Hi-Break, 3P, 3PH, 600V, 4000A current sensor rating, 4000A frame rating, 150kA@480V, 100% rated, UL listed, high interrupting capacity, suitable for reverse feed, Draw-Out, for use with MicroVersaTrip Plus trip units only, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, electrical operator with 125Vdc electrical motor operator, Solid State electronic, insulated case circuit breakers; these breakers are obsolete, however we do still stock them

EGH1125FFG, Cutler Hammer, Series G, type , 1P, 1PH, 125A, 240V, 100kA@240V, high interrupting capacity, 40°C, Feed-Thru, complete with non-interchangeable trip unit and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

SSF4G7R7U, General Electric, Power Break II, type , 3P, 3PH, 600V, 2500A current sensor rating, 100kA@480V, standard interrupting capacity, Bolt-On, front connected, 2500A frame rating, complete with Entelliguard trip, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault trip functions, full metering, modbus communication & ZSI features and 1600A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

WLS1D308DH, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 800A, 600V, 65kA@480V, UL listed, standard interrupting capacity, Draw-Out, complete with solid state ETU745 programmer + WLLCD48 LCD display + WLGFM48 ground fault module, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and 300A rating plug, Solid State electronic, low voltage insulated case circuit breakers

MDN4083LEA0822NMNH4ENHDCX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 800A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 48Vdc UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Ronis key interlock, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, without shutters, unwired

TRP2020, General Electric, type , 2P, 1PH, 20A, 240V, 1" twin "tandem" style, 10kA@240V, Plug-In, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breaker; these breakers are now obsolete, however, we do still stock them
