PDG4XPXR40800P4D, Eaton, Cutler Hammer, Power Defense, Power Xpert Release (PXR) trip units and programmers, 4P, 600V, 800A, Solid State protection, PXR25 with LSI - Long-Time, Short-Time and Instantaneous trip functions with ARMS, relays, modbus & CAM options, suitable for globally rated PDG,PDG Frame 4 circuit breakers

192A9668G5, General Electric, Primary Disconnect Assembly, All Phases, Upper and Lower Studs

HDA36070BESVYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 70A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long Time and Instantaneous trip functions, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 60 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HDA260201AABKSPYP, Square D, PowerPact, type , 2P, A & B phase connection, 1PH, 20A, 600V, 18kA@480V, UL listed, standard interrupting capacity, I-Line Style Plug-In, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, low-level, 48 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDF63P1600E3XN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 1600A, 100kA@480V, Bolt-On, no terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with relays, ZSI & CAM option, Solid State electronic, molded case circuit breakers; globally rated with 100% UL rating

HGL36090BEUO, Square D, PowerPact, type , 3P, 3PH, 90A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 24 VDC under voltage release (UVR), molded case circuit breakers

HFX3V150, Siemens, VL Series, type , 3P, 3PH, 150A, 600V, 65kA@480V , high interrupting capacity, Bolt-On, complete with non-interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, lugs not included, Solid State electronic, molded case circuit breakers

LMX3P600L, Siemens, VL Series, type , MG Frame, 3P, 3PH, 600A, 600V, 100kA@480V, very high interrupting capacity, current limiting, Feed-Thru, non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, line & load side lug terminals, digital Solid State electronic, molded case circuit breakers

KA2200V, Westinghouse, KA Series, type , 2P, 1PH, 200A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, 50°C, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

HJD63M200HL, Siemens, Sentron Series, type , 3P, 3PH, 200A, 600V, 65kA@480V, high interrupting capacity, 50ºC, Feed-Thru, 100% rated, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

JB31500MW, Westinghouse, AB DE-ION, type , 3P, 3PH, 250A, 600V, 22kA@480V, standard interrupting capacity, Bolt-On, front adjustable, magnetic trip range 750-1500A, complete with I - Instantaneous only trip function, lugs not included, Magnetic Only molded case circuit breakers; these breakers are obsolete, however we do still stock them

HDA36150U43XAEBKSKYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 5.2A non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 24 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

S4H100MW, ABB, SACE Isomax, type , 3P, 3PH, 100A, 600V, 65kA@480V, UL listed, Bolt-On, suitable for reverse feed applications, complete with I - Instantaneous protection only and load side lug terminals, MCP, motor circuit protectors, magnetic range 150-1200A, Magnetic Only, molded case circuit breakers

HDD36060, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 60A, 600V, 18kA@480V, standard interrupting capacity, Draw-Out, UL listed, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HFJ634070, Federal Pacific, HFJ Series, type , 3P, 3PH, 70A, 600V, 22kA@480V, Bolt-On, LI - Long-Time and Instantaneous trip functions, load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are now obsolete, however we do still stock them

HLL36125BEUK, Square D, PowerPact, type , 3P, 3PH, 125A, 600V, 100kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 24 VAC under voltage release (UVR), molded case circuit breakers

HJA260404AFUHYP, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 40A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, 380/480 VAC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

REE1A030, Miami Breaker, REE Series, type , 1P, 1PH, 30A, 120V, 10kA@120V, standard interrupting capacity, Bolt-On, complete with I - Instantaneous protection only and load side lug terminals, standard magnetic range, MCP, motor circuit protectors, Magnetic Only, molded case circuit breakers; these breakers are obsolete, however we still stock them

SGLC3604L5W6 General Electric Spectra Series, type , 3P, 3PH, 400A, 600V, 65kA@480V, high interrupting capacity, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIA, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm and ZSI, zone selective interlocking, RELT, reduced energy let-through & neutral protection trip functions and advanced metering, modbus & waveform capture communication features, Solid State electronic, molded case circuit breakers

SGHC3604L4M8 General Electric Spectra Series, type , 3P, 3PH, 400A, 600V, 35kA@480V, standard interrupting capacity, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIG, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault and ZSI, zone selective interlocking & neutral protection trip functions and basic metering, modbus, waveform capture & protective relays communication features, Solid State electronic, molded case circuit breakers

HHFD62B080, Siemens, Sentron Series, type , 2P, 1PH, 80A, 600V, 100kA@480V, extra high interrupting capacity, 40ºC, Bolt-On, complete with interchangeable trip unit and load side lug terminals, Thermal Magnetic molded case circuit breakers

XT5HU350BLFF000XXX, ABB, SACE Tmax XT, type , 3PH, 3P, 600V, 500A, 65kA@480V, Bolt-On, front terminals, complete with Ekip M with LIU trip functions, Ekip M DIP LIU electronic, molded case circuit breakers; 1SDA102544R1 global reference

HJL36045AFSR, Square D, PowerPact, type , 3P, 3PH, 45A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B low-level aux switch, 125 VDC shunt trip, molded case circuit breakers

HDA36110AEBKUSYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 110A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 250 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers
