SKLL3610L4N6 General Electric Spectra Series, type , 3P, 3PH, 1000A, 600V, 65kA@480V, extra high interrupting capacity, 100% rated, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSIG, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault and ZSI, zone selective interlocking, RELT, reduced energy let-through & neutral protection trip functions and advanced metering, modbus & waveform capture communication features, Solid State electronic, molded case circuit breakers

SHB5G8Z91, General Electric, Power Break II, type , 3P, 3PH, 600V, 3000A current sensor rating, 150kA@480V, high interrupting capacity, Bolt-On, back connected, 3000A frame rating, complete with Entelliguard trip, LIGA - Long-Time, Instantaneous and Ground Fault Alarm trip functions, current metering & ZSI features and 2500A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PJF36060U63BE1RD10, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 600A, 600V, 65kA@480V, UL listed, high interrupting capacity, Bolt-On, complete with direct mounted standard black handle, micrologic interchangeable power 5.0P trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs not included, Solid State electronic, molded case circuit breakers

MDN4083LEA0122NMNJ2ENYCAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

NRGF36200U63AE1, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 2000A, 600V, 35kA@480V, UL listed, standard interrupting capacity, Bolt-On, complete with micrologic interchangeable power 5.0P trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, lugs not included, Solid State electronic, molded case circuit breakers

SEF362000LSIGES5F4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 2000A, 600V, 100kA@480V, Bolt-On, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 24VDC shunt trip along with 2 N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

SHF1G2F8F, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 800A frame rating, complete with Entelliguard trip, LIG - Long-Time, Instantaneous and Ground Fault trip functions, full metering & modbus communication features and 300A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

E1B-A12-3P-1200A-DO-EO-LSI, ABB, EMax, type , 3P, 3PH, 1200A frame, 1200A rating plug, 600V, 42kA@480V, Draw-Out, electrically operated, Solid State electronic with LSI - Long-Time, Short-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers

MDN4083LEA0322NMNFNNNNCSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 220-250Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

FG3200S22, Eaton, Westinghouse, Cutler Hammer, Series C, type , 3P, 3PH, 200A, 600V, 14kA@480V, standard interrupting capacity, Feed-Thru, suitable for reverse feed applications, fixed magnetic pickup range, complete with right-pole or neutral-pole mounted 48-127Vac or 48-60Vdc, 50/60Hz rear mount shunt trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, engine generator molded case circuit breakers

PKP36100U73AE1BC, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1000A, 600V, 50kA@480V, UL listed, high interrupting capacity, Bolt-On, complete with 1A/1B alarm switch, micrologic interchangeable harmonic 5.0H trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers

WLC3F340UA, Siemens, WL Series, type , frame size III, fixed mount, 3P, 3PH, 4000A, 600V, 150kA@480V, UL listed, very high interrupting capacity, Bolt-On, complete with solid state ETU725 programmer with LSI - Long-Time, Short-Time and Instantaneous trip functions and 2000A rating plug, Solid State electronic, low voltage insulated case circuit breakers

SSB1G3C3L, General Electric, Power Break II, type , 3P, 3PH, 600V, 800A current sensor rating, 65kA@480V, standard interrupting capacity, Bolt-On, back connected, 800A frame rating, complete with Entelliguard trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, current metering & modbus communication features and 700A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

DLL36150E54, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 150A, 600V, 100kA@480V, very high interrupting capacity, UL listed, Feed-Thru, 100% rated, complete with STR53UP-FT trip with fault indicator & residual-type ground-fault protection, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

DS420-600A-EO-DO-LSIG, Cutler Hammer, DS Series, type , 2000A frame size, 300-750A trip range, electrically operated/Draw-Out, 3P, 3PH, 600A, 600V, 65kA@480V, available with Amptector or Digitrip RMS solid state trip unit, Solid State electronic, low voltage power air circuit breakers

FNT309632VSG5FB, General Electric, EntellEon, type , panelboard front, Type 1 non-vented, bottom, 30 enclosure width

SSD1G1C4B, General Electric, Power Break II, type , 3P, 3PH, 600V, 200A current sensor rating, 65kA@480V, standard interrupting capacity, Draw-Out, 800A frame, complete with Entelliguard trip, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions, current metering & modbus communication features and 150A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PLD34120CU64AE1YP, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 1200A, 480V, 100kA@480V, UL listed, very high interrupting capacity, Draw-Out, 100% rated, complete with fixed handle padlocking device, micrologic interchangeable power 6.0P trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers

NPKP36120CU64BE1, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1200A, 600V, 50kA@480V, UL listed, high interrupting capacity, Bolt-On, 100% rated, complete with micrologic interchangeable power 6.0P trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers

SSD1G2H7D, General Electric, Power Break II, type , 3P, 3PH, 600V, 400A current sensor rating, 65kA@480V, standard interrupting capacity, Draw-Out, 800A frame rating, complete with Entelliguard trip, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault trip functions, full metering, RELT, modbus communication & relays features and 225A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

5925-01-356-5974, Eaton, Naval, type , rating plug, 350A, suitable for use with AQB-L400,AQB-LL400 naval circuit breakers

MDN4083LEA0122NMNA2NHNNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB plastic frame padlockable pushbutton cover, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-127Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 2A/2B auxiliary switch & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers

MDN4083LEA0722NMNR4NNCNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 700A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, 4A/4B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Castell keylock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers

TQC1235, General Electric, Q-Line, type , 1P, 1PH, 220V, 35A, 5kA@127V, UL listed, standard interrupting capacity, Feed-Thru, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers
