LA2100SV, Westinghouse, LA Series, type , 2P, 1PH, 100A, 600V, 30kA@480V, standard interrupting capacity, Bolt-On, 50°C, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, Saf-T-Vue window and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

HDL26050ABBESV, Square D, PowerPact, type , 2P, 1PH, 50A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, 60 VDC shunt trip, molded case circuit breakers

HJA36150AABKUR, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 150A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, low-level, 125 VDC under voltage release (UVR), molded case circuit breakers

MP12H-3P-800A-MO-BO-LSIG, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 1200A frame with 800A or 1200A sensor rating and 800A rating plug, 3P, 3PH, 600V, 65kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP trip units, Solid State electronic, insulated case circuit breakers

HDA260404AFBKURYP, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 40A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, low-level, 125 VDC under voltage release (UVR), "ON" or "OFF" end handle padlock device, molded case circuit breakers

HGA36100U31XAFBE, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 100A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, molded case circuit breakers

HDL36090BCUA, Square D, PowerPact, type , 3P, 3PH, 90A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch, 120 VAC under voltage release (UVR), molded case circuit breakers

S203-D63, ABB, S 200 Series, type , 3P, 3PH, 63A, 480V, 6kA@480V, standard interrupting capacity, current limiting, DIN rail mounted, Feed-Thru, suitable for reverse feed, UL/CSA/IEC approval, branch circuit protection, D trip characteristic, Thermal Magnetic trip functions, Thermal Magnetic, miniature molded case circuit breakers and supplemental protectors

HGA36150U33XAFUP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2S non-interchangeable trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, complete with 2A/2B low-level aux switch, 48 VDC under voltage release (UVR), molded case circuit breakers

NB3900PRV, Westinghouse, TRI-PAC, type , 3P, 3PH, 900A, 600V, 30kA@480V, standard interrupting capacity, Bolt-On, 50°C, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers, these breakers are now obsolete; however, we do still stock them

KAL360901121, Square D, KAL Series, type , 3P, 3PH, 90A, 600V, 25kA@480V, standard interrupting capacity, Feed-Thru, complete with 120V undervoltage release, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic molded case circuit breakers

HLL36080AFBEUS, Square D, PowerPact, type , 3P, 3PH, 80A, 600V, 100kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B low-level aux switch, alarm switch and overcurrent trip switch, 250 VDC under voltage release (UVR), molded case circuit breakers

LXD62M400H, Siemens, Sentron Series, type , 2P, 1PH, 400A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, 50º C, 100% rated, UL listed for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic, molded case circuit breakers

HJA260154AABCUN, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 15A, 600V, 65kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch, 12 VDC under voltage release (UVR), molded case circuit breakers

HLA36100ABBCSR, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 100A, 600V, 100kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch, 125 VDC shunt trip, molded case circuit breakers

HDL26015ABBKUR, Square D, PowerPact, type , 2P, 1PH, 15A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch and overcurrent trip switch, low-level, 125 VDC under voltage release (UVR), molded case circuit breakers

HDA36150U44XAESDYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 150A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse connection, micrologic ammeter 6.2A non-interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, complete with 1A/1B low-level aux switch, 208/277 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

HJS36080C, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 80A, 600V, 65kA@480V, UL listed, current limiting, 100% rated, Bolt-On, rear connected, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HGA260154AFUD, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 15A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 2A/2B low-level aux switch, 208/277 VAC under voltage release (UVR), molded case circuit breakers

HDA260504AEBCUO, Square D, PowerPact, type , 1PH, 2P, B & C phase connection, 50A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch, 24 VDC under voltage release (UVR), molded case circuit breakers

1204KL-01W-B30-B00, Minebea part and accessory

EZD250S4200ELA, Schneider Electric, Compact, type , EZD250S, Vigi 4, 4P, 3PH, 200A, IEC rated, 690V, 50kA@415V, Bolt-On, complete with earth-fault protection and alarm, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

HDA260152AEBCSD, Square D, PowerPact, type , 1PH, 2P, A & C phase connection, 15A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch, 208/277 VAC shunt trip, molded case circuit breakers

AK-2A-75C-3000A-EO-DO, General Electric, AK Series, , 3PH, 3P, 600 VAC, 3000 Frame, Electrically Operated, Draw-Out, Low Voltage air circuit breaker, 15A-3000 A sensor rating, Available in LS, LI, LG, LSI, LIG, LSG, or LSIG Trip Functions in multiple Trip Unit Models For Use In AKD-5 Switchgear. Operating Voltage, Control Voltages, Wiring, Trip Functions, Current Sensor, Rating Plug, and Additional Accessories to be determined before ordering.
