TQL32035, General Electric, Q-Line, type , 3P, 3PH, 120/240V, 35A, 10kA@240V, UL listed, standard interrupting capacity, Plug-In, LI - Long-Time and Instantaneous trip functions, load side lug terminals, for use with PowerMark circuit breaker load centers, Thermal Magnetic, molded case circuit breakers; these breakers are obsolete, however we still stock them

ECN2429DA9, Cutler Hammer, Freedom Series, combination, non-reversing motor starter with HMCP and CPT (control power transformers), type , 3P, 3PH, 25 HP @ 575V, 600V, complete with 600V coil, NEMA size 2, 50A HMCP circuit breaker enclosed in NEMA Type 4X 316-grade stainless steel enclosure, suitable for use with Freedom Series motor control systems

EC22223AAF, Cutler Hammer, A200 Series, combination, non-reversing motor starter with HMCP, type , 3P, 3PH, 10 HP @ 200V, 10 HP @ 230V, 25 HP @ 460V, 600V, complete with 120V coil, NEMA size 2, 50A HMCP circuit breaker enclosed in NEMA Type 4 painted steel enclosure, suitable for use with A200 Series motor control systems

8539SGG44V07H30, Square D, Class 8539, combination non-reversing motor starter, NEMA size 5, requires 3 thermal units, supplied with MAG-GARD LAL36400-32M circuit breaker and NEMA type 1 enclosure, 3P, 3PH, 600V, 200 HP @ 600V, complete with 600V coil, suitable for use with Class 8539 motor control systems, Motor Logic SSOLR Class 10/20

8539SER6V06, Square D, Class 8539, combination non-reversing motor starter, NEMA size 00, requires 3 thermal units, supplied with 80A type FAL thermal magnetic circuit breaker and NEMA type 7 & 9 spin top type enclosure, 3P, 3PH, 600V, 30 HP @ 480V, complete with 480V coil, suitable for use with Class 8539 motor control systems

8539SFW54V08H20, Square D, Class 8539, combination non-reversing motor starter, NEMA size 4, requires 3 thermal units, supplied with MAG-GARD KAL36250-29M circuit breaker and NEMA type 4X enclosure, 3P, 3PH, 600V, 50 HP @ 240V, complete with 208V 60Hz coil, suitable for use with Class 8539 motor control systems, Motor Logic SSOLR Class 20

ORPK125A70, Cutler Hammer, Series C, type ORPK, interchangeable rating plug element, rated for 70A, suitable for use with the 125A current sensor rating, to be used with Series C- KD,DK,KDB,HKD,HKDB,KDC,CKD,CHKD molded case circuit breaker frame types, for use with DIGITRIPOPTIM550,DIGITRIPOPTIM1050 solid state electronic trip units & circuit breakers

A20RS20T1, Cutler Hammer, Series C, type , adjustable interchangeable rating plug element, rated for 2000A, suitable for use with 2000A current sensor rating, to be used with Series C RD,RDC,CRD,CRDC molded case circuit breaker frame types, for use with Seltronic type RS RS32000T, RS32000TG, RS42000T solid state electronic trip units & circuit breakers

KPRL4CSN direct replacement mounting hardware for Challenger, Westinghouse, Cutler Hammer, Eaton PM4a bolt-on style panel boards, rated for 1200A 600V max, Copper, Single Branch mounting style, suitable for use with CSN,CSHN,CSNY,CN,ND,CND,HND,NDC,CNDC,E2N,HMCP circuit breaker frames, complete with all associated hardware, screws and cover plates

AKR-5A-50-MO-DO-LI, General Electric, Manually Operated, Draw-out, Low Voltage air circuit breaker, AKR Series, Type , 1600A Frame, 3PH, 3P, 600Vac, {Aic Rating@480VAC}@480VAC, with ECS Solid State Overcurrent Protection, LI - Long-Time and Instantaneous trip functions, Optional Trip Functions, Current Sensor and Rating Plug Amperages available

AKR-4C-100-MO-DO-LI, General Electric, Manually Operated, Draw-out, Low Voltage air circuit breaker, AKR Series, Type , 4000A Frame, 3PH, 3P, 600Vac, {Aic Rating@480VAC}@480VAC, with SST Solid State Overcurrent Protection, LI - Long-Time and Instantaneous trip functions, Optional Trip Functions, Current Sensor and Rating Plug Amperages available

8539SGT1V06, Square D, Class 8539, combination non-reversing motor starter, NEMA size 00, requires 3 thermal units, supplied with 250A type LAL thermal magnetic circuit breaker and NEMA type 7 & 9 bolted type type enclosure, 3P, 3PH, 600V, 150 HP @ 480V, complete with 480V coil, suitable for use with Class 8539 motor control systems

8539SFW44V06H10, Square D, Class 8539, combination non-reversing motor starter, NEMA size 4, requires 3 thermal units, supplied with MAG-GARD KAL36250-29M circuit breaker and NEMA type 4 & 4X enclosure, 3P, 3PH, 600V, 100 HP @ 480V, complete with 480V coil, suitable for use with Class 8539 motor control systems, Motor Logic SSOLR Class 10

PJA36120U64AE1YV, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 1200A, 600V, 65kA@480V, UL listed, high interrupting capacity, I-Line Style Plug-In, complete with micrologic interchangeable power 6.0P trip with external voltage sensing (EVS), LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breaker

ECN2419CAB, Cutler Hammer, Freedom Series, combination, non-reversing motor starter with HMCP and CPT (control power transformers), type , 3P, 3PH, 1 HP @ 460V, 600V, complete with 480V coil, NEMA size 1, 3A HMCP circuit breaker enclosed in NEMA Type 4X 316-grade stainless steel enclosure, suitable for use with Freedom Series motor control systems

AKR-11A-50-MO-DO-LI, General Electric, Manually Operated, Draw-out, Low Voltage air circuit breaker, AKR Series, Type , 1600A Frame, 3PH, 3P, 600Vac, {Aic Rating@480VAC}@480VAC, with EntelliGuard Solid State Overcurrent Protection, LI - Long-Time and Instantaneous trip functions, Optional Trip Functions, Current Sensor and Rating Plug Amperages available

8539SGA44V01, Square D, Class 8539, combination non-reversing motor starter, NEMA size 5, requires 3 thermal units, supplied with MAG-GARD KAL36400-32M circuit breaker and NEMA type 12/3R without external reset enclosure, 3P, 3PH, 600V, 75 HP @ 240V, complete with 24V 60Hz coil, suitable for use with Class 8539 motor control systems

8539SCA3V07, Square D, Class 8539, combination non-reversing motor starter, NEMA size 1, requires 3 thermal units, supplied with 20A type FAL thermal magnetic circuit breaker and NEMA type 12/3R without external reset enclosure, 3P, 3PH, 600V, 10 HP @ 600V, complete with 600V coil, suitable for use with Class 8539 motor control systems

ORPK125A100, Cutler Hammer, Series C, type ORPK, interchangeable rating plug element, rated for 100A, suitable for use with the 125A current sensor rating, to be used with Series C- KD,DK,KDB,HKD,HKDB,KDC,CKD,CHKD molded case circuit breaker frame types, for use with DIGITRIPOPTIM550,DIGITRIPOPTIM1050 solid state electronic trip units & circuit breakers

AKR-5D-100-MO-DO-LI, General Electric, Manually Operated, Draw-out, Low Voltage air circuit breaker, AKR Series, Type , 4000A Frame, 3PH, 3P, 600Vac, {Aic Rating@480VAC}@480VAC, with ECS Solid State Overcurrent Protection, LI - Long-Time and Instantaneous trip functions, Optional Trip Functions, Current Sensor and Rating Plug Amperages available

MP20H-3P-2000A, Merlin Gerin, insulated case circuit breaker, Masterpact, type , 2000A frame, includes 2000A sensor rating with 2000A rating plug, 3P, 3PH, 600V, 75kA@480V, accepts the following programmer/trip unit devices: STR28D, STR28DP, STR38S, STR38P, STR38ST, STR38SW, STR58U, STR58UP, STR58UT, STR58UW, STR68U, AC-PRO-MP, Solid State electronic, insulated case circuit breakers

140U-JTG3-C50, Allen-Bradley, Bulletin 140U, type , interchangeable trip units and programmers, LSG - Long-Time, Short-Time and Ground Fault trip functions, rated for 50A, suitable for 250A J2L,J2H,J2G,J2I,J3L,J3H,J3G,J3I,J6L,J6H,J6G,J6I molded case circuit breaker frame types, Solid State electronic trip units & circuit breakers

8539SGG44V03H10, Square D, Class 8539, combination non-reversing motor starter, NEMA size 5, requires 3 thermal units, supplied with MAG-GARD LAL36400-32M circuit breaker and NEMA type 1 enclosure, 3P, 3PH, 600V, 75 HP @ 240V, complete with 240V coil, suitable for use with Class 8539 motor control systems, Motor Logic SSOLR Class 10

8539SFA52V06, Square D, Class 8539, combination non-reversing motor starter, NEMA size 4, requires 3 thermal units, supplied with MAG-GARD KAL36250-25M circuit breaker and NEMA type 12/3R with external reset enclosure, 3P, 3PH, 600V, 60-75 HP @ 480V, complete with 480V coil, suitable for use with Class 8539 motor control systems
