MDN4083LEA0222NMNH2NHNDSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame with factory installed block close PB plastic frame padlockable pushbutton cover, 3P, 3PH, 800A, 200A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 48Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, 2A/2B auxiliary switch, mechanical trip indicator & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, unwired

MPA31F20W4330, General Electric, M-PACT, type , frame size 1, manually operated, with 5 N.O.-3 N.C. Auxiliary switches, Mpro-50H trip unit, 220/250V dc/ac motor operator, 110/130V dc/ac closing coil and 110/130V dc/ac shunt trip, 3P, 3PH, 2000A, 690V, 50kA@415V, Bolt-On, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, insulated case circuit breakers

MURMP280, Murray Corporation, MP Series, type , 2P, 1PH, 80A, 120/240V, 10kA@240V, high interrupting capacity, 40ººC, Plug-In, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, aftermarket replacement molded case circuit breakers

WLL1D308ML, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 800A, 600V, 100kA@480V, UL listed, standard interrupting capacity, Draw-Out, complete with solid state ETU748 programmer + WLGFA48 ground fault module, LSGA - Long-Time, Short-Time and Ground Fault Alarm trip functions and 700A rating plug, Solid State electronic, low voltage insulated case circuit breakers

MDN4083LEA0422NMNRNENCNAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 208-240Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Castell keylock, load side lug terminals, Solid State, low voltage power insulated case circuit breakers

MJA363506SH, Schneider Electric, Square D, PowerPact, type , 3P, CBA reverse phase circuit configuration, 3PH, 350A, 600V, 65kA@480V, UL listed, current limiting, I-Line Style Plug-In, complete with 380/480Vac shunt trip, basic non-interchangeable 1.0 trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers

SEHD361000LSGES8A8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 1000A, 600V, 150kA@480V, high interrupt rating, Draw-Out, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 24VDC shunt closing coil & 24VDC shunt trip shunt trip along with 4A4B with 1N.O./N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

FHL360251442, Square D, FHL Series, type , 3P, 3PH, 25A, 600V, 25kA@480V, standard interrupting capacity, Feed-Thru, complete with 24Vac shunt trip and 2A/2B aux switch, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

WLH1D316DG, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 1600A, 600V, 85kA@480V, UL listed, standard interrupting capacity, Draw-Out, complete with solid state ETU745 programmer + WLGFM48 ground fault module, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and 300A rating plug, Solid State electronic, low voltage insulated case circuit breakers

SHB3G6J2M, General Electric, Power Break II, type , 3P, 3PH, 600V, 2000A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, back connected, 2000A frame rating, complete with Entelliguard trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, full metering, modbus communication & relays features and 750A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PBF31000V, Westinghouse, PBF Series, type , 3P, 3PH, 1000A, 600V, 100kA@480V, 50° C, Bolt-On, front connected, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

WLL2D320KT, Siemens, WL Series, type , frame size II, drawout, 3P, 3PH, 2000A, 600V, 100kA@480V, UL listed, high interrupting capacity, Draw-Out, complete with solid state ETU755 programmer + WLGFA76 ground fault module, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions and 600A rating plug, Solid State electronic, low voltage insulated case circuit breakers

SHF2G466H, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 100kA@480V, high interrupting capacity, Bolt-On, front connected, 1600A frame rating, complete with Entelliguard trip, LSH - Long-Time, Short-Time and High-Range Instantaneous trip functions, full metering, modbus communication & ZSI features and 400A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PLM34080U31AAA, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 800A, 480V, 100kA@480V, UL listed, very high interrupting capacity, Bolt-On, complete with 1A/1B auxiliary switch, micrologic interchangeable standard 3.0 trip, LI - Long-Time and Instantaneous trip functions and line side lug terminals, Solid State electronic, molded case circuit breakers

NEP1226LI, Square D, Pre-Micrologic, type , 2P, 1PH, 1200A, 600V, 100kA@480V, extra high interrupting capacity, Bolt-On, 100% rated, complete with older style Micrologic non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, RP100 rating plug installed and load side lug terminals, Solid State electronic, molded case circuit breakers

PLP34120CU74AE1BC, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1200A, 480V, 100kA@480V, UL listed, very high interrupting capacity, Bolt-On, 100% rated, complete with 1A/1B alarm switch, micrologic interchangeable harmonic 6.0H trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers

SED36250LSGES5F8, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 250A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 24VDC shunt trip along with 2 N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PGL36040U33BYP, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 400A, 600V, 35kA@480V, UL listed, standard interrupting capacity, Feed-Thru, complete with fixed handle padlocking device, micrologic interchangeable standard 5.0 trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

1764646, Eaton, Naval, Thermal Magnetic trip units and programmers, type -A100, 2P, 15A, 500Vac, 180-210 instantaneous trip setting, LI - Long-Time and Instantaneous trip functions, suitable for use with AQB-A100,NQB-A100 circuit breakers for naval shipboard use

TQL22080, General Electric, Q-Line, type , 2P, 1PH, 120/240V, 80A, 5kA@240V, UL listed, standard interrupting capacity, Plug-In, LI - Long-Time and Instantaneous trip functions, load side lug terminals, for use with PowerMark circuit breaker load centers, Thermal Magnetic, molded case circuit breakers; these breakers are obsolete, however we still stock them

THSS6610FC, General Electric, Power Break I, VersaTrip type , 3P, 3PH, 600V, 1000A, Front connected, 150kA@480V, high interrupting capacity, Feed-Thru, for use with VersaTrip programmers, LI - Long-Time and Instantaneous trip functions, supplied with line & load terminal studs, Thermal Magnetic insulated case circuit breakers; these breakers are obsolete, however we still stock them

SBS4040D, Siemens, SB Series, type , 3P, 3PH, 5000A frame, rated for 4000A max, 600V, 100kA@480V, standard interrupting rating, Draw-Out, Solid State electronic, insulated case circuit breakers

E6H-A50-4P-2000A-DO-EO-LI, ABB, EMax, type , 4P, 3PH, 5000A frame, 2000A rating plug, 600V, 85kA@480V, Draw-Out, electrically operated, Solid State electronic with LI - Long-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

SEF36250LSGES3F4, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 250A, 600V, 100kA@480V, Bolt-On, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 48VDC spring charging motor, shunt closing coil & shunt trip along with 2 N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them
