MDN4083LEA0422NMNANENNNSX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 400A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 110-127Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, load side lug terminals, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassette, with shutters and unwired

MPA41F1002250, General Electric, M-PACT, type , frame size 1, manually operated, with 5 N.O.-3 N.C. Auxiliary switches, 48V dc motor operator, 48V dc closing coil and 380/400V ac shunt trip, 4P, 3PH, 1000A, 690V, 50kA@415V, Bolt-On, NA - No Overcurrent Protection, Non-Automatic switch, insulated case circuit breakers

MDN4083LEA0122NMNXNNNYNWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 100A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 380-415Vac UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals & mechanical trip indicator, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

SED36600ES1D4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 600A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, shunt closing coil & shunt trip along with 2A2B with 1N.O./N.C. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

K1600-EO-BO-LSG, ABB, K-Line, type , 1600A frame size, electrically operated/Bolt-On, 3P, 3PH, 1600A, 600V, 50kA@480V, originally supplied with OD electro-mechanical overcurrent trip device, SS, MPS or MPS-C trip device but can also be retrofitted with a modern Solid State electronic trip unit with LSG - Long-Time, Short-Time and Ground Fault trip functions, low voltage power air circuit breakers

SEHF361200LIES5E8, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 1200A, 600V, 150kA@480V, high interrupt rating, Bolt-On, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 120VAC shunt closing coil & 24VDC shunt trip along with 2 N.O. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDG34K0250E3MK, Eaton, Cutler Hammer, Power Defense, type , 3PH, 4P, 600V, 250A, 50kA@480V, Bolt-On, line side lug terminals, complete with PXR20 trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and Modbus RTU & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PLL34025U33AYP, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 250A, 480V, 100kA@480V, UL listed, very high interrupting capacity, Feed-Thru, complete with fixed handle padlocking device, micrologic interchangeable standard 5.0 trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

HDA261002AABHUR, Square D, PowerPact, type , 1PH, 2P, A & C phase connection, 100A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, alarm switch low-level, 125 VDC under voltage release (UVR), molded case circuit breakers

THJK636D350WL, General Electric, J600 Line, type , 3P, 3PH, 350A, 600V, DC rated, 25kA@600V, complete with line & load side lug terminals and interchangeable trip unit, high interrupting capacity, 40°C, Feed-Thru, Thermal Magnetic, molded case circuit breakers

NPGM36060BE, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 600A, 600V, 35kA@480V, UL listed, standard interrupting capacity, Bolt-On, complete with alarm switch/overcurrent trip switch, basic non-interchangeable ET 1.0I trip, LI - Long-Time and Instantaneous trip functions and line side lug terminals, Solid State electronic, molded case circuit breakers

MDN4083LEA0522NMNJ2ENRDAX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 250A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 480Vac UVR, 2A/2B auxiliary switch, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, Ronis keylock, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers

HGA36070AEBHSHYP, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 70A, 600V, 35kA@480V, high interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch low-level, 380/480 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

GGH08L4XXXRXXX, General Electric, Entelliguard G replacement trip units and programmers, 3P, 635V, 800A sensor rating, 2000A frame size, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, suitable for use with ANSI rated ENTELLIGUARD G Low Voltage Power circuit breakers

SED364000LSES8A8, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 4000A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LS - Long-Time and Short-Time trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 24VDC shunt closing coil & 24VDC shunt trip shunt trip along with 4A4B with 1N.O./N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDG33K0400E5RL, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 400A, 50kA@480V, Bolt-On, load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

HRA36100U31XAABESPYP, Square D, PowerPact, type , 3P, ABC phase connection, 3PH, 100A, 600V, 200kA@480V, current limiting, I-Line Style Plug-In, UL listed, suitable for reverse connection, can be used for 2P applications, micrologic standard 3.2 non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, complete with 1A/1B aux switch, alarm switch and overcurrent trip switch, 48 VDC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

REH3B030L, Miami Breaker, REH Series, type , 3P, 3PH, 30A, 480V, 14kA@480V, standard interrupting capacity, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers; these breakers are now obsolete, however we do still stock them

LLD44400WU31X, Square D, Schneider Electric, PowerPact, type , 4P, 3PH, 400A, 480V, 100kA@480V, UL listed, Draw-Out, suitable for reverse connection, complete with non-interchangeable mission critical 3.3-W trip, LI - Long-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers

SKPC3612L3VX General Electric Spectra Series, type , 3P, 3PH, 1200A, 600V, 100kA@480V, extra high interrupting capacity, UL listed, suitable for reverse fed applications, complete with microEntelliGuard trip unit with LSI, LSI - Long-Time, Short-Time and Instantaneous and RELT, reduced energy let-through & neutral protection trip functions and basic metering communication features, Solid State electronic, molded case circuit breakers

SED361200LSIGES3E4, Square D, Schneider Electric, SE Series, type , 3P, 3PH, 1200A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, Solid State protection, electrically operated complete with 48VDC spring charging motor, shunt closing coil & shunt trip along with 2 N.O. AC/DC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PDG23F0225D2WN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 225A, 25kA@480V, Bolt-On, no lug terminals, complete with Xpert Release PXR20D trip with LSIZ - Long-Time, Short-Time, Instantaneous and ZSI trip functions, relays, modbus and CAM, Solid State electronic, molded case circuit breakers; globally rated

EJB34015LH, Square D, Schneider Electric, EJB Series, type , 3P, 3PH, 15A, 277/480V, 65kA@480V, extra high interrupting capacity, 40ºC, Bolt-On with mechanical lug kit, Thermal Magnetic, molded case circuit breakers

CR9500B202H3A, General Electric, Closing Solenoid Complete (for use with Quick Close), 125VDC, for electrical operation, suitable for use with AK/AKU/AKT-50(S), AK-75(S)/100(S) air circuit breakers
