SED36250LSES4C4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 250A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LS - Long-Time and Short-Time trip functions, Solid State protection, electrically operated complete with 125VDC spring charging motor, shunt closing coil & shunt trip along with 2 N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

PJP36120U63BE1RE10, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1200A, 600V, 65kA@480V, UL listed, high interrupting capacity, Bolt-On, complete with door mounted standard black handle, micrologic interchangeable power 5.0P trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers

SSD6G937U, General Electric, Power Break II, type , 3P, 3PH, 600V, 4000A current sensor rating, 100kA@480V, standard interrupting capacity, Draw-Out, 3000A frame rating, complete with Entelliguard trip, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault trip functions, current metering, modbus communication & ZSI features and 1600A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

PGL36100CU73AE1YP, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1000A, 600V, 35kA@480V, UL listed, standard interrupting capacity, Feed-Thru, 100% rated, complete with fixed handle padlocking device, micrologic interchangeable harmonic 5.0H trip, LSI - Long-Time, Short-Time and Instantaneous trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

S5N400EW, ABB, SACE Isomax, type , 3P, 3PH, 400A, 600V, 35kA@480V, 35kA@415V, Bolt-On, suitable for reverse feed applications, complete with PR212 trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions, load side lug terminals, Solid State electronic, molded case circuit breakers

KHL360901042, Square D, KHL Series, type , 3P, 3PH, 90A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, complete with 24Vac shunt trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

PDG34PH400E5XL, Cutler Hammer, Eaton, Power Defense, type , 3PH, 4P, 600V, 400A, High Override, 100kA@480V, Bolt-On, load side lug terminals, complete with PXR20 trip with ARMS LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with CAM link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

SHD4G434H, General Electric, Power Break II, type , 3P, 3PH, 600V, 1000A current sensor rating, 100kA@480V, high interrupting capacity, Draw-Out, 2500A frame rating, complete with Entelliguard trip, LSIGA - Long-Time, Short-Time, Instantaneous and Ground Fault Alarm trip functions, current metering, modbus communication & ZSI features and 400A rating plug, Solid State electronic, insulated case circuit breakers, suitable for use with Power Break II switchgear systems

HGL26070ABBHSLYP, Square D, PowerPact, type , 2P, 1PH, 70A, 600V, 35kA@480V, high interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 2A/2B aux switch, alarm switch low-level, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

LGE3500FAWCH08, Eaton, Cutler Hammer, Series G, Type , 3P, 3PH, 500A, 600V, 25kA@480V, standard interrupting capacity, UL listed for Marine applications 40°C, Bolt-On, 100% rated, complete with non-interchangeable trip unit, line & load side lug terminals not included, Thermal Magnetic molded case circuit breakers

HDA36080AAUJ, Square D, PowerPact, type , 3PH, 3P, ABC phase connection, 80A, 600V, 18kA@480V, standard interrupting capacity, I-Line Style Plug-In, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, complete with 1A/1B aux switch, 525/600 VAC under voltage release (UVR), molded case circuit breakers

E3S-A08-3P-600A-BO-MO-LI, ABB, EMax, type , 3P, 3PH, 800A frame, 600A rating plug, 600V, 65kA@480V, fixed/Bolt-On, manually operated, Solid State electronic with LI - Long-Time and Instantaneous trip functions, low voltage power insulated case circuit breakers; if accessories are needed, please call our Sales Team for assistance

MDN4083LEA0322NMNCNENYDWX, Cutler Hammer, Magnum DS, type , drawout mounted, narrow frame, 3P, 3PH, 800A, 300A current sensors and rating plugs, 600V, 42kA@600V, 40°C, Bolt-On, manually operated, complete with factory installed 24Vdc UVR, interchangeable Digitrip 220, LI - Long-Time and Instantaneous trip functions, operations counter, Kirk key interlock, load side lug terminals & latch check switch for external wiring, Solid State, low voltage power insulated case circuit breakers, shipped in drawout narrow cassettes, with shutters, pre-wired

SED36300ES8A4, Schneider Electric, Square D, SE Series, type , 3P, 3PH, 300A, 600V, 100kA@480V, Draw-Out, complete with Micrologic Series B trip device, LI - Long-Time and Instantaneous trip functions, Solid State protection, electrically operated complete with 120VAC spring charging motor, 24VDC shunt closing coil & 24VDC shunt trip along with 2A2B with 1N.O./N.C. AC rated auxiliary switch with bell alarm, insulated case circuit breakers, these breakers are now obsolete; however, we do still stock them

HDL36090BESLYP, Square D, PowerPact, type , 3P, 3PH, 90A, 600V, 18kA@480V, standard interrupting capacity, Feed-Thru, UL listed, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with alarm switch and overcurrent trip switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PDG33G0250E2RL, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 250A, 35kA@480V, Bolt-On, load side lug terminals, complete with PXR20 trip with LSI - Long-Time, Short-Time and Instantaneous trip functions, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

XT7HQ380CRFF000XXX, ABB, SACE Tmax XT, type , UL 100% rated, 3PH, 3P, 600V, 800A, 65kA@480V, Bolt-On, front terminals, complete with Ekip Touch Measuring trip, LSI - Long-Time, Short-Time and Instantaneous trip functions, Ekip Touch Measuring LSI, molded case circuit breakers; 1SDA102962R1 + 1SDA107723R1 global reference

PDG33G0125D3YN, Eaton, Cutler Hammer, Power Defense, type , 3PH, 3P, 600V, 125A, 35kA@480V, Bolt-On, no lug terminals, complete with PXR20D trip with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and Modbus RTU, CAM Link, ZSI & relays, Solid State electronic, molded case circuit breakers; CSA, IEC, UL, CCC certifications

PDG43M0500TFAL, Cutler Hammer, Eaton, Power Defense, type , 3PH, 3P, 600V, 500A, 65kA@480V, Bolt-On, load side lug terminals, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers; globally rated

HJL36090AEBESLYP, Square D, PowerPact, type , 3P, 3PH, 90A, 600V, 65kA@480V, UL listed, current limiting, Feed-Thru, suitable for reverse fed applications, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, complete with 1A/1B low-level aux switch, alarm switch and overcurrent trip switch, 48 VAC shunt trip, "ON" or "OFF" end handle padlock device, molded case circuit breakers

PLF34060U41BAC, Schneider Electric, Square D, PowerPact, type , 3P, 3PH, 600A, 480V, 100kA@480V, UL listed, very high interrupting capacity, Bolt-On, complete with 3A/3B auxiliary switch, micrologic interchangeable ammeter 3.0A trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Solid State electronic, molded case circuit breakers

PGMP4ATAM0400, General Electric, GuardEon, type , 3PH, 4P, 600V, 120-400A, 200kA@480V, 100% UL rated, front connection/Feed-Thru, toggle mechanism, complete with PremEon G interchangeable trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions with switchable GF, Solid State electronic, molded case circuit breakers; meet UL, cUL, IEC, CE, CCC requirements

PGL36120CU44BBC, Square D, Schneider Electric, PowerPact, type , 3P, 3PH, 1200A, 600V, 35kA@480V, UL listed, standard interrupting capacity, Feed-Thru, 100% rated, complete with 1A/1B alarm switch, micrologic interchangeable ammeter 6.0A trip, LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and line & load side lug terminals, Solid State electronic, molded case circuit breakers

WLH1D312PR, Siemens, WL Series, type , frame size I, drawout, 3P, 3PH, 1200A, 600V, 85kA@480V, UL listed, standard interrupting capacity, Draw-Out, complete with solid state ETU755 programmer, LSI - Long-Time, Short-Time and Instantaneous trip functions and 1000A rating plug, Solid State electronic, low voltage insulated case circuit breakers
